Lumi Brick
LBK1035
Application inspiration · not a project reference
LBK1035 is part of Lumi Brick. Coordinate the selected article’s dimensions, installation details and configuration with the project specification; these details can vary between models in the same family.
Brick Light
LBK1035
LBK1035 is a brick light family within the LUMIBRIGHT Lumi Brick collection. Explore 1 models, including LBK1035, with model-specific specifications and configuration choices. LBK1035 specifications include power: 24W; colour temperature: RGB; IP rating: IP67; dimensions: 320x320x77mm. Compare the LBK1035 range by power, colour temperature, protection rating and dimensions using the technical table below. Open an individual model to explore its available finishes and optics, select a listed order code and prepare a specification sheet where configuration data is available. Keep the chosen model reference with your project schedule so the lighting and installation teams can coordinate the same selection. For additional drawings, photometry or project-specific requirements, contact the LUMIBRIGHT specification team with your model code.
Model specifications
| Article | Wattage | CCT | IP | Dimensions | Cut-out |
|---|---|---|---|---|---|
| LBK1035 | Wattage24W | CCTRGB | IPIP67 | Dimensions320x320x77mm | Cut-outNot published |
Selected Variant
LBK1035
LBK1035.X.RGB.LKT11.120
Configuration
Select Specification
Exact match: LBK1035
All Variants (1)
| Code | Power | Beam | Finish | Size | |
|---|---|---|---|---|---|
| LBK1035 | 24W | 120° | lkt11 | 320x320x77mm |
Dimensions
Technical Drawing
Drawing and sizes shown for model LBK1035.
Size — model LBK1035
320x320x77mm
Technical Data
Full Specification
| Dimensions | 320x320x77mm |
|---|---|
| Cut-out | Not published — technical review required |
| Power | 24W |
| Lumen output | Not published — technical review required |
| Efficacy | Not published — technical review required |
| Optics / beam angle | 120° |
| Colour temperature | Not published — technical review required |
| CRI Ra | Not published — technical review required |
| R9 | Not published — technical review required |
| TM-30 Rf / Rg | Not published — technical review required |
| UGR | Not published — technical review required |
| IP rating | IP67 |
| IK rating | Not published — technical review required |
| Ambient temperature (Ta) | Not published — technical review required |
| Driver | Not published — technical review required |
| Dimming / control | Not published — technical review required |
| Input voltage | 24VDC |
| Light source | Not published — technical review required |
| Material | Not published — technical review required |
| Finish | lkt11 |
| Mounting / installation | Not published — technical review required |
| Net weight | Not published — technical review required |
| Certification | Not published — technical review required |
| Lifetime | Not published — technical review required |
| Warranty | Not published — technical review required |
| Lead time | Not published — technical review required |
6 of 26 specification rows published from the 2026 master data. Values vary by model; missing test data is not estimated. Select an exact model for approval.
Specifications
At a Glance
24W
Power
120°
Beam Angle
IP67
Protection Rating
lkt11
Body Finish
320x320x77mm
Dimensions
