Lumi Flex

FLEXI GRAZER

Application inspiration · not a project reference

FLEXI GRAZER is part of Lumi Flex. Coordinate the selected article’s dimensions, installation details and configuration with the project specification; these details can vary between models in the same family.

Lighting Accessory

6 product lines·6 total variants·luminaire·cove lighting

FLEXI GRAZER is a lighting accessory family within the LUMIBRIGHT Lumi Flex collection. The current catalogue groups 6 article codes under this family, including LFW1001, LFW1002, LFW1003. For LFW1001, published values include power: 36W; colour temperature: 3000K, 4000K, 5000K; IP rating: IP67; dimensions: 66x29x1000mm. Each article represents its own physical model; dimensions and electrical or optical options must be checked against that exact code. Compare the FLEXI GRAZER articles using the specification table and individual model pages before adding them to a lighting schedule. Wattage, colour temperature, protection rating and installation dimensions are catalogue values, not a guarantee that every combination can be ordered. Where a value is not published, request the relevant model documentation rather than assuming it matches another article. Confirm the selected configuration, driver requirements, installation detail and project documentation with the specification team before ordering.

Model specifications

Article	Wattage	CCT	IP	Dimensions	Cut-out
LFW1001	Wattage36W	CCT3000K, 4000K, 5000K	IPIP67	Dimensions66x29x1000mm	Cut-outNot published
LFW1002	Wattage12W	CCT3000K, 4000K, 5000K	IPIP67	Dimensions66x29x333.3mm	Cut-outNot published
LFW1003	Wattage24W	CCT3000K, 4000K, 5000K	IPIP67	Dimensions66x29x666mm	Cut-outNot published
LFW1004	Wattage48W	CCT3000K, 4000K, 5000K	IPIP67	Dimensions66x29x1333mm	Cut-outNot published
LFW1005	Wattage60W	CCT3000K, 4000K, 5000K	IPIP67	Dimensions66x29x1666mm	Cut-outNot published
LFW1006	Wattage72W	CCT3000K, 4000K, 5000K	IPIP67	Dimensions66x29x2000mm	Cut-outNot published

Technical Data

Full Specification

Dimensions	66x29x1000mm · 66x29x333.3mm · 66x29x666mm · 66x29x1333mm +2 more
Cut-out	Not published — technical review required
Power	12W · 24W · 36W · 48W +2 more
Lumen output	Not published — technical review required
Efficacy	Not published — technical review required
Optics / beam angle	120°
Colour temperature	3000K · 4000K · 5000K
CRI Ra	Not published — technical review required
R9	Not published — technical review required
TM-30 Rf / Rg	Not published — technical review required
UGR	Not published — technical review required
IP rating	IP20 · IP67
IK rating	Not published — technical review required
Ambient temperature (Ta)	Not published — technical review required
Driver	Not published — technical review required
Dimming / control	Not published — technical review required
Input voltage	24VDC
Light source	Not published — technical review required
Material	Not published — technical review required
Finish	Not published — technical review required
Mounting / installation	Not published — technical review required
Net weight	Not published — technical review required
Certification	Not published — technical review required
Lifetime	Not published — technical review required
Warranty	Not published — technical review required
Lead time	Not published — technical review required

6 of 26 specification rows published from the 2026 master data. Values vary by model; missing test data is not estimated. Select an exact model for approval.

How to compare compatible model, output or current, dimensions and supplied quantity →

Configuration

Select Specification

Power

Beam Angle

CCT

IP Rating

Select attributes to narrow down variants

Product Lines

6 Products

LFW1001

LUMIFLEX FLEXI GRAZER 36W 24VDC FLEXIBLE WALL WASHER IP67

36W120°IP6766x29x1000mm

1 variant

LFW1002

LUMIFLEX FLEXI GRAZER 12W 24VDC FLEXIBLE WALL WASHER IP67

12W120°IP6766x29x333.3mm

1 variant

LFW1003

LUMIFLEX FLEXI GRAZER 24W 24VDC FLEXIBLE WALL WASHER IP67

24W120°IP6766x29x666mm

1 variant

LFW1004

LUMIFLEX FLEXI GRAZER 48W 24VDC FLEXIBLE WALL WASHER IP67

48W120°IP6766x29x1333mm

1 variant

LFW1005

LUMIFLEX FLEXI GRAZER 60W 24VDC FLEXIBLE WALL WASHER IP67

60W120°IP6766x29x1666mm

1 variant

LFW1006

LUMIFLEX FLEXI GRAZER 72W 24VDC FLEXIBLE WALL WASHER IP67

72W120°IP6766x29x2000mm

1 variant

Dimensions

Technical Drawing

Drawing and sizes shown for model LFW1002. This family has 6 models with different dimensions — select a model above, or open its row in the variant table, for its own drawing.

Size — model LFW1002

66x29x333.3mm

Specifications

At a Glance

12–72W

Power Range

1 options

Beam: 120°

3 CCT

3000K, 4000K, 5000K

IP67

Protection Rating

6 sizes

66x29x1000mm, 66x29x1333mm, 66x29x1666mm, 66x29x2000mm, 66x29x333.3mm, 66x29x666mm

Model

Model details ↗

Configure your product

LFW1002

Colour temperature

3000K · 4000K · 5000K

Beam angle

120°

Dimming

On/Off · DALI · 1-10V · 0-10V · Phase

The published options are not mapped to a confirmed order code. Technical review is required before issuing a configuration-specific specification sheet.
