Lumi Flex
SMD 3030
Application inspiration · not a project reference
SMD 3030 is part of Lumi Flex. Coordinate the selected article’s dimensions, installation details and configuration with the project specification; these details can vary between models in the same family.
Strip Light
SMD 3030
SMD 3030 is a strip light family within the LUMIBRIGHT Lumi Flex collection. Explore 2 models, including LF1166, LF1167, with model-specific specifications and configuration choices. LF1166 specifications include power: 8W/m; colour temperature: 3000K, 4000K, 5000K; IP rating: IP67; dimensions: 23x11x5000mm. Compare the SMD 3030 range by power, colour temperature, protection rating and dimensions using the technical table below. Open an individual model to explore its available finishes and optics, select a listed order code and prepare a specification sheet where configuration data is available. Keep the chosen model reference with your project schedule so the lighting and installation teams can coordinate the same selection. For additional drawings, photometry or project-specific requirements, contact the LUMIBRIGHT specification team with your model code.
Model specifications
| Article | Wattage | CCT | IP | Dimensions | Cut-out |
|---|---|---|---|---|---|
| LF1166 | Wattage8W/m | CCT3000K, 4000K, 5000K | IPIP67 | Dimensions23x11x5000mm | Cut-outNot published |
| LF1167 | Wattage24W/m | CCT3000K, 4000K, 5000K | IPIP67 | Dimensions23x11x5000mm | Cut-outNot published |
Product View
Selected Variant
LF1167
LUMIFLEX 23X11X5000MM 24W/M 42LED/M 24VDC SMD 3030 IP67 LED WALL WASHER STRIP LIGHT LF1167
Configuration
Select Specification
Exact match: LF1167
Complete Your Setup
Recommended accessories for LF1167
All Variants (1)
| Code | Power | CCT | Beam | CRI | Size | |
|---|---|---|---|---|---|---|
| LF1167 | 24W | 3000K, 4000K, 5000K | 120° | 80 | 23x11x5000mm |
Dimensions
Technical Drawing
Drawing and sizes shown for model LF1167.
Size — model LF1167
23x11x5000mm
Technical Data
Full Specification
| Dimensions | 23x11x5000mm |
|---|---|
| Cut-out | Not published — technical review required |
| Power | 8W · 24W |
| Lumen output | Not published — technical review required |
| Efficacy | Not published — technical review required |
| Optics / beam angle | 120° |
| Colour temperature | 3000K · 4000K · 5000K |
| CRI Ra | 80 |
| R9 | Not published — technical review required |
| TM-30 Rf / Rg | Not published — technical review required |
| UGR | Not published — technical review required |
| IP rating | IP67 |
| IK rating | Not published — technical review required |
| Ambient temperature (Ta) | Not published — technical review required |
| Driver | Not published — technical review required |
| Dimming / control | Not published — technical review required |
| Input voltage | 24VDC |
| Light source | Not published — technical review required |
| Material | Not published — technical review required |
| Finish | Not published — technical review required |
| Mounting / installation | Not published — technical review required |
| Net weight | Not published — technical review required |
| Certification | Not published — technical review required |
| Lifetime | Not published — technical review required |
| Warranty | Not published — technical review required |
| Lead time | Not published — technical review required |
7 of 26 specification rows published from the 2026 master data. Values vary by model; missing test data is not estimated. Select an exact model for approval.
Specifications
At a Glance
24W
Power
120°
Beam Angle
3 CCT
3000K, 4000K, 5000K
CRI 80
Colour Rendering
IP67
Protection Rating
23x11x5000mm
Dimensions
Configure your product
LF1167
Colour temperature
3000K · 4000K · 5000K
Beam angle
120°
Dimming
On/Off · DALI · 1-10V · 0-10V · Phase
The published options are not mapped to a confirmed order code. Technical review is required before issuing a configuration-specific specification sheet.
