Neon Flex
SMD 3535+2835
SMD 3535+2835 is a neon flex family within the LUMIBRIGHT Lumi Flex collection. Explore 6 models, including LF5068, LF5068.X.8RGBCW.17.WP, LF5090, with model-specific specifications and configuration choices. LF5068 specifications include power: 17W/m; colour temperature: 3000K, 4000K, 5000K; IP rating: IP68; dimensions: Ø11.50x21mm. Compare the SMD 3535+2835 range by power, colour temperature, protection rating and dimensions using the technical table below. Open an individual model to explore its available finishes and optics, select a listed order code and prepare a specification sheet where configuration data is available. Keep the chosen model reference with your project schedule so the lighting and installation teams can coordinate the same selection. For additional drawings, photometry or project-specific requirements, contact the LUMIBRIGHT specification team with your model code.
Model specifications
| Article | Wattage | CCT | IP | Dimensions | Cut-out |
|---|---|---|---|---|---|
| LF5068 | Wattage17W/m | CCT3000K, 4000K, 5000K | IPIP68 | DimensionsØ11.50x21mm | Cut-outNot published |
| LF5068.X.8RGBCW.17.WP | Wattage17W/m | CCTRGBCW | IPIP68 | DimensionsØ11.50x21mm | Cut-outNot published |
| LF5090 | Wattage17W/m | CCT3000K, 4000K, 5000K | IPIP68 | DimensionsØ11.5x28mm | Cut-outNot published |
| LF5090.X.8RGBCW.17.WP | Wattage17W/m | CCTRGBCW(2700+6500K) | IPIP68 | DimensionsØ11.5x28mm | Cut-outNot published |
| LF5110 | Wattage17W/m | CCT3000K, 4000K, 5000K | IPIP68 | Dimensions11.5x28mm | Cut-outNot published |
| LF5110.X.8RGBCW.17.WP | Wattage17W/m | CCTRGBCW(2700+6500K) | IPIP68 | Dimensions11.5x28mm | Cut-outNot published |
Technical Data
Full Specification
| Dimensions | Ø11.50x21mm · Ø11.5x28mm · 11.5x28mm |
|---|---|
| Cut-out | Not published — technical review required |
| Power | 17W |
| Lumen output | Not published — technical review required |
| Efficacy | Not published — technical review required |
| Optics / beam angle | 120° |
| Colour temperature | 3000K · 4000K · 5000K |
| CRI Ra | Not published — technical review required |
| R9 | Not published — technical review required |
| TM-30 Rf / Rg | Not published — technical review required |
| UGR | Not published — technical review required |
| IP rating | IP68 |
| IK rating | Not published — technical review required |
| Ambient temperature (Ta) | Not published — technical review required |
| Driver | Not published — technical review required |
| Dimming / control | Not published — technical review required |
| Input voltage | 24VDC |
| Light source | Not published — technical review required |
| Material | Not published — technical review required |
| Finish | Not published — technical review required |
| Mounting / installation | Not published — technical review required |
| Net weight | Not published — technical review required |
| Certification | Not published — technical review required |
| Lifetime | Not published — technical review required |
| Warranty | Not published — technical review required |
| Lead time | Not published — technical review required |
6 of 26 specification rows published from the 2026 master data. Values vary by model; missing test data is not estimated. Select an exact model for approval.
Configuration
Select Specification
Select attributes to narrow down variants
Product Lines
5 Products
Dimensions
Technical Drawing
Drawing and sizes shown for model LF5068.X.8RGBCW.17.WP. This family has 5 models with different dimensions — select a model above, or open its row in the variant table, for its own drawing.
Size — model LF5068.X.8RGBCW.17.WP
Ø11.50x21mm
Specifications
At a Glance
17W
Power Range
1 options
Beam: 120°
3 CCT
3000K, 4000K, 5000K
IP68
Protection Rating
3 sizes
11.5x28mm, Ø11.50x21mm, Ø11.5x28mm
Configure your product
LF5068.X.8RGBCW.17.WP
Colour temperature
3000K · 4000K · 5000K
Beam angle
120°
Dimming
On/Off · DALI · 1-10V · 0-10V · Phase
The published options are not mapped to a confirmed order code. Technical review is required before issuing a configuration-specific specification sheet.
