Lumi Indoor
LILLY
Application inspiration · not a project reference
LILLY is part of Lumi Indoor. Coordinate the selected article’s dimensions, installation details and configuration with the project specification; these details can vary between models in the same family.
Spot Light
LILLY
Technical Data
Full Specification
| Dimensions | Φ59.5xH67.3 · Φ39.8xH57.5 · Φ60xH82 · Φ70xH85 +3 more |
|---|---|
| Cut-out | Φ55 · Φ40 · Φ52 · Φ60 +2 more |
| Power | 10W · 5W · 15W |
| Lumen output | 1500LM |
| Efficacy | Not published — technical review required |
| Optics / beam angle | 20° · 24° · 40° · 36° |
| Colour temperature | 2700K · 3000K · 4000K · 5000K +1 more |
| CRI Ra | 90 · ≥90 |
| R9 | Not published — technical review required |
| TM-30 Rf / Rg | Not published — technical review required |
| UGR | Not published — technical review required |
| IP rating | IP20 · IP65 |
| IK rating | Not published — technical review required |
| Ambient temperature (Ta) | Not published — technical review required |
| Driver | Not published — technical review required |
| Dimming / control | Not published — technical review required |
| Input voltage | 220-240VAC |
| Light source | Not published — technical review required |
| Material | white+ Matt Black, white+ Matt White · white+ Matt Black, White, Black · White, Black |
| Finish | white · black · WHITE+MATT WHITE · WHITE+MATT BLACK +2 more |
| Mounting / installation | Not published — technical review required |
| Net weight | Not published — technical review required |
| Certification | Not published — technical review required |
| Lifetime | Not published — technical review required |
| Warranty | Not published — technical review required |
| Lead time | Not published — technical review required |
11 of 26 specification rows published from the 2026 master data. Values vary by model; missing test data is not estimated. Select an exact model for approval.
Configuration
Select Specification
Select attributes to narrow down variants
Product Lines
7 Products
Dimensions
Technical Drawing
Drawing and sizes shown for model LBE2148. This family has 7 models with different dimensions — select a model above, or open its row in the variant table, for its own drawing.
Size — model LBE2148
Φ59.5xH67.3
Cut-Out
Φ55
Specifications
At a Glance
5–15W
Power Range
4 options
Beam: 20°, 24°, 36°, 40°
5 CCT
2700K, 3000K, 4000K, 5000K, 6000K
CRI 90
Colour Rendering
IP20 / IP65
Protection Rating
5 finishes
Body Finish Options
7 sizes
Ø45x70mm, Φ39.5xH51.2, Φ39.8xH57.5, Φ59.5xH67.3, Φ60xH82, Φ70xH85, Φ74.5xH85
6 cut-outs
Φ35, Φ40, Φ52, Φ55, Φ60, Φ70
Configure your product
LBE2148
Order code
Listed configurationLBE2148.C.960.WWH.40.DR
20 listed configurations · availability requires confirmation
