Lumi Outdoor

ASMIR

Application inspiration · not a project reference

ASMIR is part of Lumi Outdoor. Coordinate the selected article’s dimensions, installation details and configuration with the project specification; these details can vary between models in the same family.

Inground Light

6 variants·luminaire·floor recessed

ASMIR is a inground light family within the LUMIBRIGHT Lumi Outdoor collection. The current catalogue groups 1 article codes under this family, including LB1299. For LB1299, published values include power: 3W; colour temperature: 3000K; IP rating: IP67; dimensions: Ø42x67mm. Each article represents its own physical model; dimensions and electrical or optical options must be checked against that exact code. Compare the ASMIR articles using the specification table and individual model pages before adding them to a lighting schedule. Wattage, colour temperature, protection rating and installation dimensions are catalogue values, not a guarantee that every combination can be ordered. Where a value is not published, request the relevant model documentation rather than assuming it matches another article. Confirm the selected configuration, driver requirements, installation detail and project documentation with the specification team before ordering.

Model specifications

Article	Wattage	CCT	IP	Dimensions	Cut-out
LB1299	Wattage3W	CCT3000K	IPIP67	DimensionsØ42x67mm	Cut-outNot published

Configuration

Select Specification

Power

Beam Angle

CCT

Finish

IP Rating

Select attributes to narrow down variants

All Variants (6)

Code	Power	CCT	Beam	CRI	Finish	Size
LB1299	—	3000K, 4000K, 6000K	—	—	—	—
LB1299	3W	3000K	30°	80	stainless-steel	Ø42x67mm
LB1299	3W	3000K	30°	80	anodized-in-aluminum	Ø42x67mm
LB1299	3W	4000K	30°	80	stainless-steel	Ø42x67mm
LB1299	—	6000K	—	80	—	Ø42x67mm
LB1299	3W	6000K	30°	80	stainless-steel	Ø42x67mm

Dimensions

Technical Drawing

Drawing and sizes shown for model LB1299.

Size — model LB1299

Ø42x67mm

Technical Data

Full Specification

Dimensions	Ø42x67mm
Cut-out	Not published — technical review required
Power	3W
Lumen output	Not published — technical review required
Efficacy	Not published — technical review required
Optics / beam angle	30°
Colour temperature	3000K · 4000K · 6000K
CRI Ra	80
R9	Not published — technical review required
TM-30 Rf / Rg	Not published — technical review required
UGR	Not published — technical review required
IP rating	IP67
IK rating	Not published — technical review required
Ambient temperature (Ta)	Not published — technical review required
Driver	Not published — technical review required
Dimming / control	Not published — technical review required
Input voltage	constant-current
Light source	Not published — technical review required
Material	Not published — technical review required
Finish	stainless-steel · anodized-in-Aluminium · Stainless Steel · Anodized In Aluminium
Mounting / installation	Not published — technical review required
Net weight	Not published — technical review required
Certification	Not published — technical review required
Lifetime	Not published — technical review required
Warranty	Not published — technical review required
Lead time	Not published — technical review required

8 of 26 specification rows published from the 2026 master data. Values vary by model; missing test data is not estimated. Select an exact model for approval.
