Lumi Outdoor
BAZINO R
Application inspiration · not a project reference
BAZINO R is part of Lumi Outdoor. Coordinate the selected article’s dimensions, installation details and configuration with the project specification; these details can vary between models in the same family.
Underwater Light
BAZINO R
BAZINO R is a underwater light family within the LUMIBRIGHT Lumi Outdoor collection. The current catalogue groups 1 article codes under this family, including LBS1428. For LBS1428, published values include power: 18W; colour temperature: 4000K; IP rating: IP68; dimensions: Ø260x33mm. Each article represents its own physical model; dimensions and electrical or optical options must be checked against that exact code. Compare the BAZINO R articles using the specification table and individual model pages before adding them to a lighting schedule. Wattage, colour temperature, protection rating and installation dimensions are catalogue values, not a guarantee that every combination can be ordered. Where a value is not published, request the relevant model documentation rather than assuming it matches another article. Confirm the selected configuration, driver requirements, installation detail and project documentation with the specification team before ordering.
Model specifications
| Article | Wattage | CCT | IP | Dimensions | Cut-out |
|---|---|---|---|---|---|
| LBS1428 | Wattage18W | CCT4000K | IPIP68 | DimensionsØ260x33mm | Cut-outNot published |
Configuration
Select Specification
Select attributes to narrow down variants
All Variants (10)
| Code | Power | CCT | Beam | Finish | Size | |
|---|---|---|---|---|---|---|
| LBS1428 | — | 2700K, 3000K, 4000K, 6000K | — | — | — | |
| LBS1428 | 18W | — | 120° | stainless-steel | Ø260x33mm | |
| LBS1428 | 18W | — | 120° | stainless-steel | Ø260x33mm | |
| LBS1428 | 18W | — | 120° | stainless-steel | Ø260x33mm | |
| LBS1428 | 18W | — | 120° | stainless-steel | Ø260x33mm | |
| LBS1428 | 18W | — | 120° | stainless-steel | Ø260x33mm | |
| LBS1428 | 18W | — | 120° | stainless-steel | Ø260x33mm | |
| LBS1428 | 18W | — | 120° | stainless-steel | Ø260x33mm | |
| LBS1428 | 18W | — | 120° | stainless-steel | Ø260x33mm | |
| LBS1428 | 18W | — | — | — | Ø260x33mm |
Dimensions
Technical Drawing
Drawing and sizes shown for model LBS1428.
Size — model LBS1428
Ø260x33mm
Technical Data
Full Specification
| Dimensions | Ø260x33mm |
|---|---|
| Cut-out | Not published — technical review required |
| Power | 18W |
| Lumen output | Not published — technical review required |
| Efficacy | Not published — technical review required |
| Optics / beam angle | 120° |
| Colour temperature | 2700K · 3000K · 4000K · 6000K +4 more |
| CRI Ra | No CRI · 80 |
| R9 | Not published — technical review required |
| TM-30 Rf / Rg | Not published — technical review required |
| UGR | Not published — technical review required |
| IP rating | IP68 |
| IK rating | Not published — technical review required |
| Ambient temperature (Ta) | Not published — technical review required |
| Driver | Not published — technical review required |
| Dimming / control | Not published — technical review required |
| Input voltage | 24VDC |
| Light source | Not published — technical review required |
| Material | Not published — technical review required |
| Finish | stainless-steel · Stainless Steel |
| Mounting / installation | Not published — technical review required |
| Net weight | Not published — technical review required |
| Certification | Not published — technical review required |
| Lifetime | Not published — technical review required |
| Warranty | Not published — technical review required |
| Lead time | Not published — technical review required |
8 of 26 specification rows published from the 2026 master data. Values vary by model; missing test data is not estimated. Select an exact model for approval.
Specifications
At a Glance
18W
Power
120°
Beam Angle
4 CCT
2700K, 3000K, 4000K, 6000K
BLUE / GREEN / RED / RGB
Colour Options
IP68
Protection Rating
stainless-steel
Body Finish
Ø260x33mm
Dimensions
Configure your product
LBS1428
Order code
Listed configurationLBS1428.X.RGB.SSS.120
8 listed configurations · availability requires confirmation
