Underwater Light
GANYMIDIS
GANYMIDIS is a underwater light family within the LUMIBRIGHT Lumi Outdoor collection. Explore 3 models, including LB1410, LB1496, LBT1104, with model-specific specifications and configuration choices. LB1410 specifications include power: 4W; colour temperature: 2700K. Compare the GANYMIDIS range by power, colour temperature, protection rating and dimensions using the technical table below. Open an individual model to explore its available finishes and optics, select a listed order code and prepare a specification sheet where configuration data is available. Keep the chosen model reference with your project schedule so the lighting and installation teams can coordinate the same selection. For additional drawings, photometry or project-specific requirements, contact the LUMIBRIGHT specification team with your model code.
Model specifications
| Article | Wattage | CCT | IP | Dimensions | Cut-out |
|---|---|---|---|---|---|
| LB1410 | Wattage4W | CCT2700K | IPNot published | DimensionsNot published | Cut-outNot published |
| LB1496 | Wattage3W | CCT3000K | IPIP68 | DimensionsØ52x79.5mm | Cut-outNot published |
| LBT1104 | WattageNot published | CCTNot published | IPIP67 | DimensionsØ25x50mm | Cut-outNot published |
Technical Data
Full Specification
| Dimensions | Ø52x79.5mm · Ø25x50mm |
|---|---|
| Cut-out | Ø18mm |
| Power | 0.2W · 3W |
| Lumen output | Not published — technical review required |
| Efficacy | Not published — technical review required |
| Optics / beam angle | 10° · 30° · 45° · 60° +1 more |
| Colour temperature | 2700K · 3000K · 4000K · 6000K +3 more |
| CRI Ra | Not published — technical review required |
| R9 | Not published — technical review required |
| TM-30 Rf / Rg | Not published — technical review required |
| UGR | Not published — technical review required |
| IP rating | IP68 · IP67 |
| IK rating | Not published — technical review required |
| Ambient temperature (Ta) | Not published — technical review required |
| Driver | Not published — technical review required |
| Dimming / control | Not published — technical review required |
| Input voltage | 12VDC |
| Light source | Not published — technical review required |
| Material | Not published — technical review required |
| Finish | Stainless Steel · stainless-steel |
| Mounting / installation | Not published — technical review required |
| Net weight | Not published — technical review required |
| Certification | Not published — technical review required |
| Lifetime | Not published — technical review required |
| Warranty | Not published — technical review required |
| Lead time | Not published — technical review required |
8 of 26 specification rows published from the 2026 master data. Values vary by model; missing test data is not estimated. Select an exact model for approval.
Configuration
Select Specification
Select attributes to narrow down variants
Dimensions
Technical Drawing
Drawing and sizes shown for model LBT1104. This family has 3 models with different dimensions — select a model above, or open its row in the variant table, for its own drawing.
Size — model LBT1104
Ø25x50mm
Cut-Out
Ø18mm
Specifications
At a Glance
0.2–3W
Power Range
5 options
Beam: 10°, 30°, 45°, 60°, 90°
4 CCT
2700K, 3000K, 4000K, 6000K
BLUE / GREEN / RED
Colour Options
IP67 / IP68
Protection Rating
1 finishes
Body Finish Options
2 sizes
Ø25x50mm, Ø52x79.5mm
Ø18mm
Cut-Out
Configure your product
LB1496
Order code
Listed configurationLB1496.W.830.SSS.60
35 listed configurations · availability requires confirmation
