Lumi Outdoor

IRISH

Application inspiration · not a project reference

IRISH is part of Lumi Outdoor. Coordinate the selected article’s dimensions, installation details and configuration with the project specification; these details can vary between models in the same family.

Linear System

6 product lines·27 total variants·system·linear system

IRISH is a linear system family within the LUMIBRIGHT Lumi Outdoor collection. The current catalogue groups 6 article codes under this family, including L06006, L06007, L06008. For L06006, published values include power: 12W; colour temperature: 2700K, 3000K, 4000K, 5000K, 6000K, 6500K; IP rating: IP66; dimensions: L1000xW16xH34mm. Each article represents its own physical model; dimensions and electrical or optical options must be checked against that exact code. Compare the IRISH articles using the specification table and individual model pages before adding them to a lighting schedule. Wattage, colour temperature, protection rating and installation dimensions are catalogue values, not a guarantee that every combination can be ordered. Where a value is not published, request the relevant model documentation rather than assuming it matches another article. Confirm the selected configuration, driver requirements, installation detail and project documentation with the specification team before ordering.

Model specifications

Article	Wattage	CCT	IP	Dimensions	Cut-out
L06006	Wattage12W	CCT2700K, 3000K, 4000K, 5000K, 6000K, 6500K	IPIP66	DimensionsL1000xW16xH34mm	Cut-outNot published
L06007	Wattage12W	CCT2700K, 3000K, 4000K, 5000K, 6000K, 6500K	IPIP66	DimensionsL1000xW16xH34mm	Cut-outNot published
L06008	Wattage12W	CCT2700K, 3000K, 4000K, 5000K, 6000K, 6500K	IPIP66	DimensionsL1000xW20xH35mm	Cut-outNot published
L06009	Wattage12W	CCT2700K, 3000K, 4000K, 5000K, 6000K, 6500K	IPIP66	DimensionsL1000xW20xH35mm	Cut-outNot published
L06010	Wattage12W	CCT2700K, 3000K, 4000K, 5000K, 6000K, 6500K	IPIP66	DimensionsL1000xW25xH33mm	Cut-outNot published
L06011	Wattage12W	CCT2700K, 3000K, 4000K, 5000K, 6000K, 6500K	IPIP66	DimensionsL1000xW25xH33mm	Cut-outNot published

Technical Data

Full Specification

Dimensions	L1000xW16xH34mm · L1000xW20xH35mm · L1000xW25xH33mm
Cut-out	Not published — technical review required
Power	12W
Lumen output	Not published — technical review required
Efficacy	75LM/W
Optics / beam angle	120°
Colour temperature	2700K · 3000K · 4000K · 5000K +3 more
CRI Ra	80 · No CRI
R9	Not published — technical review required
TM-30 Rf / Rg	Not published — technical review required
UGR	Not published — technical review required
IP rating	IP66
IK rating	Not published — technical review required
Ambient temperature (Ta)	Not published — technical review required
Driver	Not published — technical review required
Dimming / control	Not published — technical review required
Input voltage	Not published — technical review required
Light source	Not published — technical review required
Material	Not published — technical review required
Finish	Grey
Mounting / installation	Not published — technical review required
Net weight	Not published — technical review required
Certification	Not published — technical review required
Lifetime	Not published — technical review required
Warranty	Not published — technical review required
Lead time	Not published — technical review required

8 of 26 specification rows published from the 2026 master data. Values vary by model; missing test data is not estimated. Select an exact model for approval.
