Lumi Outdoor
PENTAIR
Application inspiration · not a project reference
PENTAIR is part of Lumi Outdoor. Coordinate the selected article’s dimensions, installation details and configuration with the project specification; these details can vary between models in the same family.
Underwater Light
PENTAIR
Technical Data
Full Specification
| Dimensions | Ø260x40MM · Ø240x40mm · Ø290x49.5mm |
|---|---|
| Cut-out | Not published — technical review required |
| Power | 25W |
| Lumen output | Not published — technical review required |
| Efficacy | Not published — technical review required |
| Optics / beam angle | 120° |
| Colour temperature | 2700K · 3000K · 4000K · 6000K +4 more |
| CRI Ra | No CRI · 80 |
| R9 | Not published — technical review required |
| TM-30 Rf / Rg | Not published — technical review required |
| UGR | Not published — technical review required |
| IP rating | IP68 |
| IK rating | Not published — technical review required |
| Ambient temperature (Ta) | Not published — technical review required |
| Driver | Not published — technical review required |
| Dimming / control | Not published — technical review required |
| Input voltage | 12VDC · 24VDC |
| Light source | Not published — technical review required |
| Material | Not published — technical review required |
| Finish | white · stainless-steel · Stainless Steel |
| Mounting / installation | Not published — technical review required |
| Net weight | Not published — technical review required |
| Certification | Not published — technical review required |
| Lifetime | Not published — technical review required |
| Warranty | Not published — technical review required |
| Lead time | Not published — technical review required |
8 of 26 specification rows published from the 2026 master data. Values vary by model; missing test data is not estimated. Select an exact model for approval.
Configuration
Select Specification
Select attributes to narrow down variants
Product Lines
10 Products
Dimensions
Technical Drawing
Drawing and sizes shown for model LBS1436. This family has 10 models with different dimensions — select a model above, or open its row in the variant table, for its own drawing.
Size — model LBS1436
Ø290x49.5mm
Specifications
At a Glance
18–42W
Power Range
1 options
Beam: 120°
4 CCT
2700K, 3000K, 4000K, 6000K
BLUE / GREEN / RED / RGB
Colour Options
IP68
Protection Rating
2 finishes
Body Finish Options
3 sizes
Ø240x40mm, Ø260x40MM, Ø290x49.5mm
Configure your product
LBS1420
Order code
Listed configurationLBS1420.X.RGB.WWH.120
8 listed configurations · availability requires confirmation
