Lumi Outdoor
VEJLE
Application inspiration · not a project reference
VEJLE is part of Lumi Outdoor. Coordinate the selected article’s dimensions, installation details and configuration with the project specification; these details can vary between models in the same family.
Inground Light
VEJLE
VEJLE is a inground light family within the LUMIBRIGHT Lumi Outdoor collection. Explore 25 models, including L09050, L09051, L09052, with model-specific specifications and configuration choices. L09050 specifications include power: 10W; colour temperature: 2700K/3000K/4000K/5000K/6000K/6500K; IP rating: IP67; dimensions: Ø100x115mm. Compare the VEJLE range by power, colour temperature, protection rating and dimensions using the technical table below. Open an individual model to explore its available finishes and optics, select a listed order code and prepare a specification sheet where configuration data is available. Keep the chosen model reference with your project schedule so the lighting and installation teams can coordinate the same selection. For additional drawings, photometry or project-specific requirements, contact the LUMIBRIGHT specification team with your model code.
Model specifications
| Article | Wattage | CCT | IP | Dimensions | Cut-out |
|---|---|---|---|---|---|
| L09050 | Wattage10W | CCT2700K/3000K/4000K/5000K/6000K/6500K | IPIP67 | DimensionsØ100x115mm | Cut-outNot published |
| L09051 | Wattage10W | CCT2700K/3000K/4000K/5000K/6000K/6500K | IPIP67 | DimensionsØ100x115mm | Cut-outNot published |
| L09052 | Wattage10W | CCT2700K/3000K/4000K/5000K/6000K/6500K | IPIP67 | DimensionsØ100x115mm | Cut-outNot published |
| L09053 | Wattage10W | CCT2700K/3000K/4000K/5000K/6000K/6500K | IPIP67 | DimensionsØ100x115mm | Cut-outNot published |
| L09054 | Wattage10W | CCT2700K/3000K/4000K/5000K/6000K/6500K | IPIP67 | DimensionsØ100x115mm | Cut-outNot published |
| L09055 | Wattage7W | CCT2700K/3000K/4000K/5000K/6000K/6500K | IPIP67 | DimensionsØ80x85mm | Cut-outNot published |
| L09056 | Wattage7W | CCT2700K/3000K/4000K/5000K/6000K/6500K | IPIP67 | DimensionsØ80x85mm | Cut-outNot published |
| L09057 | Wattage7W | CCT2700K/3000K/4000K/5000K/6000K/6500K | IPIP67 | DimensionsØ80x85mm | Cut-outNot published |
| L09058 | Wattage7W | CCT2700K/3000K/4000K/5000K/6000K/6500K | IPIP67 | DimensionsØ80x85mm | Cut-outNot published |
| L09059 | Wattage7W | CCT2700K/3000K/4000K/5000K/6000K/6500K | IPIP67 | DimensionsØ80x85mm | Cut-outNot published |
| L09060 | Wattage5W | CCT2700K/3000K/4000K/5000K/6000K/6500K | IPIP67 | DimensionsØ64x74mm | Cut-outNot published |
| L09061 | Wattage5W | CCT2700K/3000K/4000K/5000K/6000K/6500K | IPIP67 | DimensionsØ64x74mm | Cut-outNot published |
| L09062 | Wattage5W | CCT2700K/3000K/4000K/5000K/6000K/6500K | IPIP67 | DimensionsØ64x74mm | Cut-outNot published |
| L09063 | Wattage5W | CCT2700K/3000K/4000K/5000K/6000K/6500K | IPIP67 | DimensionsØ64x74mm | Cut-outNot published |
| L09064 | Wattage5W | CCTRGBW | IPIP67 | DimensionsØ64x74mm | Cut-outNot published |
| L09065 | Wattage2.5W | CCT2700K/3000K/4000K/5000K/6000K/6500K | IPIP67 | DimensionsØ52x75mm | Cut-outNot published |
| L09066 | Wattage2.5W | CCT2700K/3000K/4000K/5000K/6000K/6500K | IPIP67 | DimensionsØ52x75mm | Cut-outNot published |
| L09067 | Wattage2.5W | CCTRGBW | IPIP67 | DimensionsØ52x75mm | Cut-outNot published |
| L09068 | Wattage1.5W | CCT2700K/3000K/4000K/5000K/6000K/6500K | IPIP67 | DimensionsØ38x75mm | Cut-outNot published |
| L09069 | Wattage1.5W | CCT2700K/3000K/4000K/5000K/6000K/6500K | IPIP67 | DimensionsØ38x75mm | Cut-outNot published |
| L09070 | Wattage2W | CCTRGBW | IPIP67 | DimensionsØ38x60mm | Cut-outNot published |
| L12000 | Wattage16W | CCT2700K, 3000K, 4000K, 5000K, 6000K, 6500K | IPIP65 | DimensionsNot published | Cut-outNot published |
| L12001 | Wattage16W | CCT2700K, 3000K, 4000K, 5000K, 6000K, 6500K | IPIP65 | DimensionsNot published | Cut-outNot published |
| L12002 | Wattage16W | CCT2700K, 3000K, 4000K, 5000K, 6000K, 6500K | IPIP65 | DimensionsNot published | Cut-outNot published |
| L12003 | Wattage16W | CCT2700K, 3000K, 4000K, 5000K, 6000K, 6500K | IPIP65 | DimensionsNot published | Cut-outNot published |
Technical Data
Full Specification
| Dimensions | Ø100x115mm · Ø80x85mm · Ø64x74mm · Ø52x75mm +2 more |
|---|---|
| Cut-out | Not published — technical review required |
| Power | 1.5W · 2W · 2.5W · 5W +2 more |
| Lumen output | Not published — technical review required |
| Efficacy | 60-70lm/W |
| Optics / beam angle | 3° · 5° · 6° · 12° +15 more |
| Colour temperature | 2700K · 3000K · 4000K · 5000K +4 more |
| CRI Ra | 80/90 |
| R9 | Not published — technical review required |
| TM-30 Rf / Rg | Not published — technical review required |
| UGR | Not published — technical review required |
| IP rating | IP67 · IP65 |
| IK rating | Not published — technical review required |
| Ambient temperature (Ta) | Not published — technical review required |
| Driver | Not published — technical review required |
| Dimming / control | Not published — technical review required |
| Input voltage | 110-130VAC · 24VDC · 220-240VAC · 110-240VAC |
| Light source | Not published — technical review required |
| Material | Aluminium DIE-CAST |
| Finish | Stainless Steel · Black |
| Mounting / installation | Not published — technical review required |
| Net weight | Not published — technical review required |
| Certification | Not published — technical review required |
| Lifetime | Not published — technical review required |
| Warranty | Not published — technical review required |
| Lead time | Not published — technical review required |
10 of 26 specification rows published from the 2026 master data. Values vary by model; missing test data is not estimated. Select an exact model for approval.
Configuration
Select Specification
Select attributes to narrow down variants
Product Lines
24 Products
Dimensions
Technical Drawing
Drawing and sizes shown for model L09066. This family has 24 models with different dimensions — select a model above, or open its row in the variant table, for its own drawing.
Size — model L09066
Ø52x75mm
Specifications
At a Glance
1.5–16W
Power Range
9 options
Beam: 3°, 5°, 6°, 12°, 15°, 18°, 20°, 25°, 30°
7 CCT
2700K, 3000K, 4000K, 5000K, 5700K, 6000K, 6500K
RGB+WARM WHITE
Colour Options
CRI 80/90
Colour Rendering
IP65 / IP67
Protection Rating
2 finishes
Body Finish Options
6 sizes
Ø100x115mm, Ø38x60mm, Ø38x75mm, Ø52x75mm, Ø64x74mm, Ø80x85mm
Configure your product
L09066
Order code
Listed configurationL09066.865.03.60
42 listed configurations · availability requires confirmation
