JOYERIA
Application inspiration · not a project reference
JOYERIA is part of Lumi Sys. Coordinate the selected article’s dimensions, installation details and configuration with the project specification; these details can vary between models in the same family.
Magnetic Light
JOYERIA
JOYERIA is a magnetic light family within the LUMIBRIGHT Lumi Sys collection. Explore 11 models, including LBMG438, LBMG439, LBMG440, with model-specific specifications and configuration choices. LBMG438 specifications include power: 1.2W; colour temperature: 2700K/3000K/3500K/4000K/5000K/6500K; IP rating: IP20; dimensions: Ø12xL23.5mm. Compare the JOYERIA range by power, colour temperature, protection rating and dimensions using the technical table below. Open an individual model to explore its available finishes and optics, select a listed order code and prepare a specification sheet where configuration data is available. Keep the chosen model reference with your project schedule so the lighting and installation teams can coordinate the same selection. For additional drawings, photometry or project-specific requirements, contact the LUMIBRIGHT specification team with your model code.
Model specifications
| Article | Wattage | CCT | IP | Dimensions | Cut-out |
|---|---|---|---|---|---|
| LBMG438 | Wattage1.2W | CCT2700K/3000K/3500K/4000K/5000K/6500K | IPIP20 | DimensionsØ12xL23.5mm | Cut-outNot published |
| LBMG439 | Wattage2x1W | CCT2700K/3000K/3500K/4000K/5000K/6500K | IPIP20 | DimensionsØ12xL23.5mm | Cut-outNot published |
| LBMG440 | Wattage1.5W | CCT2700K/3000K/3500K/4000K/5000K/6500K | IPIP20 | DimensionsØ19xL32mm | Cut-outNot published |
| LBMG441 | Wattage2W | CCT2700K/3000K/3500K/4000K/5000K/6500K | IPIP20 | DimensionsØ19xL40mm | Cut-outNot published |
| LBMG442 | Wattage3x2W | CCT2700K/3000K/3500K/4000K/5000K/6500K | IPIP20 | DimensionsØ26xL106xW32xH23mm | Cut-outNot published |
| LBMG443 | Wattage3W | CCT2700K/3000K/3500K/4000K/5000K/6500K | IPIP20 | DimensionsØ22x49mm | Cut-outNot published |
| LBMG444 | Wattage3W | CCT2700K/3000K/3500K/4000K/5000K/6500K | IPIP20 | DimensionsØ22x49x500mm | Cut-outNot published |
| LBMG445 | Wattage4W | CCT2700K/3000K/3500K/4000K/5000K/6500K | IPIP20 | DimensionsØ28x60mm | Cut-outNot published |
| LBMG446 | Wattage3W | CCT2700K/3000K/3500K/4000K/5000K/6500K | IPIP20 | DimensionsØ28x60x500mm | Cut-outNot published |
| LBMG447 | Wattage4W | CCT2700K/3000K/3500K/4000K/5000K/6500K | IPIP20 | DimensionsØ42x40mm | Cut-outNot published |
| LBMG448 | Wattage2W | CCT2700K/3000K/3500K/4000K | IPIP20 | DimensionsØ23x78mm | Cut-outNot published |
Technical Data
Full Specification
| Dimensions | W19 x H16.65mm · Ø12xL23.5mm · Ø19xL32mm · Ø19xL40mm +7 more |
|---|---|
| Cut-out | Not published — technical review required |
| Power | 1.2W · 2x1W · 1.5W · 2W +3 more |
| Lumen output | Not published — technical review required |
| Efficacy | Not published — technical review required |
| Optics / beam angle | 20°/35°/50° · 15° / 30° / 50° · 15° /20° / 25° / 30° / 40° · 15° / 25° / 55° +3 more |
| Colour temperature | 2700K/3000K/3500K/4000K/5000K/6500K · 2700K · 3000K · 3500K +4 more |
| CRI Ra | ≥90 · ≥97 |
| R9 | Not published — technical review required |
| TM-30 Rf / Rg | Not published — technical review required |
| UGR | Not published — technical review required |
| IP rating | IP20 |
| IK rating | Not published — technical review required |
| Ambient temperature (Ta) | Not published — technical review required |
| Driver | Not published — technical review required |
| Dimming / control | Not published — technical review required |
| Input voltage | 24VDC |
| Light source | Not published — technical review required |
| Material | Not published — technical review required |
| Finish | Black |
| Mounting / installation | Not published — technical review required |
| Net weight | Not published — technical review required |
| Certification | Not published — technical review required |
| Lifetime | Not published — technical review required |
| Warranty | Not published — technical review required |
| Lead time | Not published — technical review required |
8 of 26 specification rows published from the 2026 master data. Values vary by model; missing test data is not estimated. Select an exact model for approval.
Configuration
Select Specification
Select attributes to narrow down variants
Product Lines
11 Products
Dimensions
Technical Drawing
Drawing and sizes shown for model LBMG447. This family has 11 models with different dimensions — select a model above, or open its row in the variant table, for its own drawing.
Size — model LBMG447
Ø42x40mm
Specifications
At a Glance
1.2–6W
Power Range
4 options
Beam: 5°, 14°, 15°, 20°
6 CCT
2700K, 3000K, 3500K, 4000K, 5000K, 6500K
CRI 90/97
Colour Rendering
IP20
Protection Rating
10 sizes
Ø12xL23.5mm, Ø19xL32mm, Ø19xL40mm, Ø22x49mm, Ø22x49x500mm, Ø23x78mm, Ø26xL106xW32xH23mm, Ø28x60mm, Ø28x60x500mm, Ø42x40mm
Accessories & components
All accessories ↗
LBMGA178
JOYERIA LBMGA178 - RECESSED TRACK
LBMGA176
JOYERIA LBMGA176 - SURFACE TRACK
LBMGA176
JOYERIA LBMGA176 - SURFACE TRACK
LBMGA177
JOYERIA LBMGA177 - END CAP
LBMGA177
JOYERIA LBMGA177 - END CAP
LBMGA178
JOYERIA LBMGA178 - RECESSED TRACK
LBMGA179
JOYERIA LBMGA179 - END CAP
LBMGA179
JOYERIA LBMGA179 - END CAP
LBMGA180
JOYERIA LBMGA180 - RECESSED TRACK
LBMGA180
JOYERIA LBMGA180 - RECESSED TRACK
LBMGA181
JOYERIA LBMGA181 - END CAP
LBMGA181
JOYERIA LBMGA181 - END CAP
LBMGA215
JOYERIA LBMGA215 - TRACK RAIL
LBMGA215
JOYERIA LBMGA215 - TRACK RAIL
