Lumi Ville
FONTA
FONTA is part of Lumi Ville. Coordinate the selected article’s dimensions, installation details and configuration with the project specification; these details can vary between models in the same family.
FONTA is a wall light family within the LUMIBRIGHT Lumi Ville collection. Explore 16 models, including LVU4043, LVU4044, LVU4045, with model-specific specifications and configuration choices. LVU4043 specifications include colour temperature: 2700K, 3000K; IP rating: IP65; dimensions: Ø60x68x210mm. Compare the FONTA range by power, colour temperature, protection rating and dimensions using the technical table below. Open an individual model to explore its available finishes and optics, select a listed order code and prepare a specification sheet where configuration data is available. Keep the chosen model reference with your project schedule so the lighting and installation teams can coordinate the same selection. For additional drawings, photometry or project-specific requirements, contact the LUMIBRIGHT specification team with your model code.
Model specifications
| Article | Wattage | CCT | IP | Dimensions | Cut-out |
|---|---|---|---|---|---|
| LVU4043 | Not published | 2700K, 3000K | IP65 | Ø60x68x210mm | Not published |
| LVU4044 | 4.0-8.0W | 2700K, 3000K | IP65 | Ø60x68x210mm | Not published |
| LVU4045 | Not published | 2700K, 3000K | IP65 | Ø60x75x210mm | Not published |
| LVU4046 | Not published | 2700K, 3000K | IP65 | Ø60x75x210mm | Not published |
| LVU4047 | Not published | 2700K, 3000K | IP54 | 65x95x160mm | Not published |
| LVU4048 | Not published | 2700K, 3000K | IP65 | Ø60x85x263 | Not published |
| LVU4049 | Not published | 2700K, 3000K | IP65 | Ø60x85x263 | Not published |
| LVU4050 | Not published | 2700K, 3000K | IP65 | Ø60x75x135mm | Not published |
| LVU4051 | Not published | 2700K, 3000K | IP65 | Ø60x75x135mm | Not published |
| LVU4052 | Not published | 2700K, 3000K | IP65 | Ø60x125x85mm | Not published |
| LVU4053 | 4.0-8.0W | 2700K, 3000K | IP65 | Ø60x125x85mm | Not published |
| LVU4054 | Not published | 2700K, 3000K | IP54 | 97x65x116mm | Not published |
| LVU4055 | Not published | 2700K, 3000K | IP65 | Ø60x174xØ68mm | Not published |
| LVU4056 | 4.0-8.0W | 2700K, 3000K | IP65 | Ø60x174xØ68mm | Not published |
| LVU4057 | Not published | 2700K, 3000K | P65 | 220x220x85mm | Not published |
| LVU4058 | Not published | 2700K, 3000K | P65 | 220x220x95mm | Not published |
Models (16)
- LVU4043
- LVU4044
- LVU4045
- LVU4046
- LVU4047
- LVU4048
- LVU4049
- LVU4050
- LVU4051
- LVU4052
- LVU4053
- LVU4054
- LVU4055
- LVU4056
- LVU4057
- LVU4058
Family options are ranges, not guarantees for every model. Select an exact article and configuration.
