LBP2004 Spot Light

LBP2004: specifications and applications

LBP2004 is the SPOT LBP2004 - SPOT LIGHT lighting model in the lumi arc catalogue, listed under SPOT LIGHT. This page keeps the specifications, configuration choices and project notes for LBP2004 together, so it can be compared with other SPARK models without substituting the dimensions or options of a neighbouring article.

The LBP2004 catalogue record lists power: 10W. Coordinate this load with the circuit schedule and the selected control gear.

The LBP2004 catalogue record lists body dimensions: Ø106xH42mm. Check the housing against the architectural detail and the space reserved for installation.

The LBP2004 catalogue record lists cut-out: Ø90-95mm. Use the opening dimension separately from the outside body size when coordinating the finished surface.

The LBP2004 catalogue record lists colour temperature: 3000K, 4000K, 5000K. Compare the listed colour choices with finishes, surrounding light and the intended atmosphere.

The LBP2004 catalogue record lists colour rendering: 80+/90+. Include this catalogue value in the material and display-lighting comparison for the project.

The LBP2004 catalogue record lists optical distribution: 90°. Compare the listed option with target distance, spacing and the surface being illuminated.

The LBP2004 catalogue record lists enclosure rating: IP20. Coordinate this rating with the actual exposure, cleaning regime and installation conditions.

The LBP2004 catalogue record lists electrical requirement: 200-240VAC. Keep the stated unit alongside the driver and control specification; a current rating must not be treated as a mains voltage.

The LBP2004 catalogue record lists finish or material: White. Review the stated construction alongside adjoining architectural materials and sample approvals.

The LBP2004 catalogue record lists mounting: track-mounted. Check the fixing arrangement and access for installation before finalising the detail.

Accent lighting for retail, hospitality and residential interiors starts with the object or surface that needs emphasis. Compare the selected optic with the target size and mounting distance, and review colour appearance alongside surrounding finishes. A clear model and configuration reference helps the lighting schedule distinguish focused feature lighting from the general lighting elsewhere in the same space.

LBP2004 has 1 listed order-code configuration. The listed code is LBP2004.S.8CCTS.WWH.90.DR. Use the exact listed combination when selecting finishes, colour temperature or optical options; an option appearing elsewhere in the family is not automatically an orderable combination for this article.

For a LBP2004 project submission, retain this model reference with the drawings and the selected configuration. Include the relevant dimensions, optical information and installation requirements in the coordination review. Where a document or value is not available on the page, request the model-specific information from the specification team rather than copying a value from another SPARK article.

Main model page: LBP2004

Model specifications

Light SourceCOB
Power10W
Input Voltage200-240VAC
Driver250mA/25-40VDC
CRI80+/90+
Colour Temperature3000K/4000K/5000K (Switchable)
Beam Angle90°
Power Factor0.90
IP RatingIP20
LED Life Time50,000Hrs
DimensionsØ106xH42mm
Cut-OutØ90-95mm
Body FinishWhite
MaterialAluminum
HeatsinkDie cast aluminum
WarrantyWritten eligibility and policy confirmation required
Catalogue conformity claim (evidence not verified)CE
Luminous Efficacy100-105lm/W

LBP2004 datasheet
