LUMIBRIGHT
ASTIN
LUMI INDOOR
ceiling-recessed
IP20

LBE3021 Down Light

BASE: LBE3021

ASTIN lighting solution with professional specifications

ASTIN LBE3021 - DOWN LIGHT
Specifications at a Glance
30W
Power
2800lm
Lumen Output
2700K3000K4000K5000K6000K6500K
Available Colour Temperatures
CRI 80
Colour Rendering Index
IP20
Protection Rating
60°
Beam Angle
220-240VAC
Input
140mm
Cutout Size
160xH90MM
Body Dimensions
White
Available Finishes
DALINon-DimmableTriac
Dimming Options
ceiling-recessed
Mounting Type
BRIDGELUX
LED Chip
50,000Hrs
LED Life Time
Aluminum
Material
Technical evidence & warranty

Supporting model-specific declarations/test reports require verification

Evidence requirementsWarranty status

AVAILABLE CONFIGURATIONS

12 listed configurations · availability requires confirmation

Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.

LBE3021.N.940.WWH.60.DR
CCT:
4000K
Power:30W
Lumen:2800lm
Beam:
60°
Finish:
White
CRI 80IP20
LBE3021.N.840.WWH.60.DR
CCT:
4000K
Power:30W
Lumen:2800lm
Beam:
60°
Finish:
White
CRI 80IP20
LBE3021.W.930.WWH.60.DR
CCT:
3000K
Power:30W
Lumen:2800lm
Beam:
60°
Finish:
White
CRI 80IP20
LBE3021.C.965.WWH.60.DR
CCT:
6500K
Power:30W
Lumen:2800lm
Beam:
60°
Finish:
White
CRI 80IP20
LBE3021.C.850.WWH.60.DR
CCT:
5000K
Power:30W
Lumen:2800lm
Beam:
60°
Finish:
White
CRI 80IP20
LBE3021.C.860.WWH.60.DR
CCT:
6000K
Power:30W
Lumen:2800lm
Beam:
60°
Finish:
White
CRI 80IP20

Need Custom Options?

Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.

Questions about configurations? Contact our sales team for technical assistance.
Compatible Accessories
1 items

Recommended accessories for optimal installation and performance

Accessories

Additional components

1

Product Information

Category:
DOWN LIGHT
Series:
Astin
Family:
ASTIN
Dimension:
160xH90MM
Input Voltage:
220-240VAC
Light Source:
BRIDGELUX
Material:
Aluminum
Life Time:
50,000Hrs
Cut-Out:
140mm

Catalogue Specification

Light Source:
BRIDGELUX
Product Type:
SPOTLIGHT
Power:
30W
Input Voltage:
220-240VAC
Lumen Output:
2800lm
Colour Temperature:
2700K/3000K/4000K/5000K/6000K/6500K
CRI:
80
IP Rating:
IP20
Beam Angle:
60°
Material:
Aluminum
Body Finish:
White
Dimensions:
160xH90MM
Cut-Out:
140mm
LED Life Time:
50,000Hrs
Warranty:
Written eligibility and policy confirmation required

Applications

Jewellery Display
Office
