L01262 Ceiling Light
BASE: L01262BEYNAC lighting solution with professional specifications
Specifications at a Glance
15W
Power
100LM
Lumen Output
2700K3000K4000K6000K
Available Colour Temperatures
CRI 90
Colour Rendering Index
IP65
Protection Rating
15° / 24° / 38° / 60°
Beam Angle
REFLECTOR
UGR / Optics
220-240VAC
Input
L75×W75mm
Cutout Size
L85×W85×H94mm
Body Dimensions
White
Available Finishes
DALINon-DimmableTriac
Dimming Options
ceiling-recessed
Mounting Type
BRIDGELUX
LED Chip
ALUMINUM
Material
Technical evidence & warranty
Supporting model-specific declarations/test reports require verification
Evidence requirementsWarranty statusAVAILABLE CONFIGURATIONS
16 listed configurations · availability requires confirmation
Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.
L01262.960.01.60.DR
CCT:
6000K
Power:15W
Lumen:100LM
Beam:
60°
Finish:
CRI 90IP65White
L01262.960.01.38.DR
CCT:
6000K
Power:15W
Lumen:100LM
Beam:
38°
Finish:
CRI 90IP65White
L01262.960.01.24.DR
CCT:
6000K
Power:15W
Lumen:100LM
Beam:
24°
Finish:
CRI 90IP65White
L01262.960.01.15.DR
CCT:
6000K
Power:15W
Lumen:100LM
Beam:
15°
Finish:
CRI 90IP65White
L01262.940.01.60.DR
CCT:
4000K
Power:15W
Lumen:100LM
Beam:
60°
Finish:
CRI 90IP65White
L01262.940.01.38.DR
CCT:
4000K
Power:15W
Lumen:100LM
Beam:
38°
Finish:
CRI 90IP65White
Need Custom Options?
Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.
Questions about configurations? Contact our sales team for technical assistance.
Product Information
- Category:
- CEILING RECESSED LIGHT
- Series:
- BEYNAC
- Family:
- BEYNAC
- Dimension:
- L85×W85×H94mm
- Input Voltage:
- 220-240VAC
- Light Source:
- BRIDGELUX
- Material:
- ALUMINUM
- Cut-Out:
- L75×W75mm
Catalogue Specification
- Light Source:
- BRIDGELUX
- Power:
- 15W
- Input Voltage:
- 220-240VAC
- Colour Temperature:
- 2700K/3000K/4000K/6000K/6500K
- Beam Angle:
- 15°/24°/38°/60°
- CRI:
- 90
- IP Rating:
- IP65
- Body Finish:
- WHITE/BLACK
- Dimensions:
- L85×W85×H94mm
- Cut-Out:
- L75×W75mm
- Optics:
- REFLECTOR
- Cover / Lens:
- PC
- Material:
- ALUMINUM
- Luminous Efficacy:
- 100lm/w
Applications
Jewellery Display
Office
Configure your product
L01262
Order code
Listed configurationL01262.960.01.60.DR
16 listed configurations · availability requires confirmation
