LUMIBRIGHT
CALLEJON
LUMI INDOOR
ceiling-recessed
IP65/IP20

L01177 Ceiling Light

BASE: L01177

CALLEJON lighting solution with professional specifications

CALLEJON L01177 - CEILING RECESSED LIGHT
Specifications at a Glance
7W
Power
542LM
Lumen Output
2700K3000K4000K
Available Colour Temperatures
CRI 90+
Colour Rendering Index
IP65
Protection Rating
50°
Beam Angle
LENS
UGR / Optics
350mA
Input
Ø48mm
Cutout Size
Ø55x64mm
Body Dimensions
BlackWhite
Available Finishes
DALINon-DimmableTriac
Dimming Options
ceiling-recessed
Mounting Type
LED
LED Chip
ALUMINUM
Material
Technical evidence & warranty

Supporting model-specific declarations/test reports require verification

Evidence requirementsWarranty status

AVAILABLE CONFIGURATIONS

6 listed configurations · availability requires confirmation

Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.

L01177.940.03.50
CCT:
4000K
Power:7W
Lumen:542LM
Beam:
50°
Finish:
Black
CRI 90+IP65
L01177.940.01.50
CCT:
4000K
Power:7W
Lumen:542LM
Beam:
50°
Finish:
White
CRI 90+IP65
L01177.930.03.50
CCT:
3000K
Power:7W
Lumen:542LM
Beam:
50°
Finish:
Black
CRI 90+IP65
L01177.930.01.50
CCT:
3000K
Power:7W
Lumen:542LM
Beam:
50°
Finish:
White
CRI 90+IP65
L01177.927.03.50
CCT:
2700K
Power:7W
Lumen:542LM
Beam:
50°
Finish:
Black
CRI 90+IP65
L01177.927.01.50
CCT:
2700K
Power:7W
Lumen:542LM
Beam:
50°
Finish:
White
CRI 90+IP65

Need Custom Options?

Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.

Questions about configurations? Contact our sales team for technical assistance.
Compatible Accessories

Product Information

Category:
CEILING RECESSED LIGHT
Series:
CALLEJON
Family:
CALLEJON
Dimension:
Ø55x64mm
Input Voltage:
350mA
Light Source:
LED
Material:
ALUMINUM
Cut-Out:
Ø48mm

Catalogue Specification

Light Source:
LED
Power:
7W
Input Voltage:
350mA
Colour Temperature:
2700K/3000K/4000K/6000K/6500K
Lumen Output:
542LM
Beam Angle:
50°
CRI:
90+
IP Rating:
IP65/IP20
Body Finish:
WHITE/BLACK
Dimensions:
Ø55x64mm
Cut-Out:
Ø48mm
Optics:
LENS
Cover / Lens:
PC
Material:
ALUMINUM

Applications

Jewellery Display
