CORSO
LUMI INDOOR
L13006 Panel Light
BASE: L13006LUMIBRIGHT CORSO SERIES 36W Ø1195x595x30mm IP54 LED BACKLIT PANEL LIGHT L13006
Specifications at a Glance
36W
Power
6400LM
Lumen Output
4000K
Available Colour Temperatures
IP54
Protection Rating
110°
Beam Angle
UGR<19
UGR / Optics
220-240VAC(With Driver)
Input
1195x595x30mm
Body Dimensions
White
Available Finishes
Non-DimmableDALITriac0/1-10V
Dimming Options
SANAN
LED Chip
50,000Hrs
LED Life Time
ALUMINUM DIE-CAST
Material
-10°C~+40°C
Operating Temperature
INDOOR
Usage
Technical evidence & warranty
Supporting model-specific declarations/test reports require verification
Evidence requirementsWarranty statusListed configuration
L13006.865.01.110.DR
AVAILABLE CONFIGURATIONS
5 listed configurations · availability requires confirmation
Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.
L13006.865.01.110.DR
Power:36W
Lumen:6400lm
Beam:
110°
Finish:
IP54White
L13006.860.01.110.DR
Power:36W
Lumen:6400lm
Beam:
110°
Finish:
IP54White
L13006.850.01.110.DR
Power:36W
Lumen:6400lm
Beam:
110°
Finish:
IP54White
L13006.840.01.110.DR
Power:36W
Lumen:6400lm
Beam:
110°
Finish:
IP54White
L13006.830.01.110.DR
Power:36W
Lumen:6400lm
Beam:
110°
Finish:
IP54White
Need Custom Options?
Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.
Questions about configurations? Contact our sales team for technical assistance.
Product Information
- Category:
- PANEL LIGHT
- Series:
- CORSO
- Family:
- CORSO
- Dimension:
- 1195x595x30mm
- Input Voltage:
- 220-240VAC(With Driver)
- Light Source:
- SANAN
- Material:
- ALUMINUM DIE-CAST
- Life Time:
- 50,000Hrs
- Operating Temp:
- -10°C~+40°C
- Usage:
- INDOOR
Catalogue Specification
- Light Source:
- SANAN
- Power:
- 36W
- Input Voltage:
- 220-240VAC(With Driver)
- Colour Temperature:
- 4000K
- Lumen Output:
- 6400LM
- Beam Angle:
- 110°/90°
- CRI:
- 80
- IP Rating:
- IP54
- Body Finish:
- WHITE
- Dimensions:
- 1195x595x30mm
- Optics:
- DIFFUSER
- Cover / Lens:
- PC
- Material:
- ALUMINUM DIE-CAST
Applications
Education
Jewellery Display
