LB1024 Track Light
BASE: LB1024LUMIBRIGHT CRANE LUMIINDOOR 32W TRACK LIGHT IP20
Specifications at a Glance
32W
Power
2800lm
Lumen Output
3000
Available Colour Temperatures
IP20
Protection Rating
30° / 45°
Beam Angle
220-240VAC
Input
Ø93x115mm
Body Dimensions
White
Available Finishes
track-mounted
Mounting Type
BRIDGELUX LED
LED Chip
50,000Hrs
LED Life Time
Aluminum
Material
-25°C~+50°C
Operating Temperature
INDOOR
Usage
Technical evidence & warranty
Supporting model-specific declarations/test reports require verification
Evidence requirementsWarranty statusAVAILABLE CONFIGURATIONS
2 listed configurations · availability requires confirmation
Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.
LB1024.W.830.PAB.30
Power:32W
Lumen:2800lm
Beam:
30°
Finish:
IP20White
LB1024.N.840.PAW.45
Power:32W
Lumen:2800lm
Beam:
45°
Finish:
IP20White
Need Custom Options?
Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.
Questions about configurations? Contact our sales team for technical assistance.
Product Information
- Category:
- TRACK LIGHT
- Family:
- CRANE
- Dimension:
- Ø93x115mm
- Input Voltage:
- 220-240VAC
- Light Source:
- BRIDGELUX LED
- Material:
- Aluminum
- Life Time:
- 50,000Hrs
- Operating Temp:
- -25°C~+50°C
- Usage:
- INDOOR
Applications
Hospitality
Jewellery Display
Retail
Configure your product
LB1024
Order code
Listed configurationLB1024.W.830.PAB.30
2 listed configurations · availability requires confirmation
