LBT3009 Down Light
BASE: LBT3009DEEP lighting solution with professional specifications
Specifications at a Glance
25W
Power
2733lm
Lumen Output
2700K3000K
Available Colour Temperatures
CRI 80+
Colour Rendering Index
IP54
Protection Rating
60°
Beam Angle
UGR<19
UGR / Optics
220-240VAC With Driver
Input
Ø120-Ø130mm
Cutout Size
Ø145x65mm
Body Dimensions
White
Available Finishes
Non-DimmableDALITriac0/1-10V
Dimming Options
ceiling-recessed
Mounting Type
COB LED
LED Chip
50,000Hrs
LED Life Time
Aluminum+PC
Material
Technical evidence & warranty
Supporting model-specific declarations/test reports require verification
Evidence requirementsWarranty statusAVAILABLE CONFIGURATIONS
2 listed configurations · availability requires confirmation
Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.
LBT3009.W.827.WWH.60.DR
CCT:
2700K
Power:25W
Lumen:2733lm
Beam:
60°
Finish:
CRI 80+IP54White
LBT3009.W.830.WWH.60.DR
CCT:
3000K
Power:25W
Lumen:2733lm
Beam:
60°
Finish:
CRI 80+IP54White
Need Custom Options?
Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.
Questions about configurations? Contact our sales team for technical assistance.
Product Information
- Category:
- DOWN LIGHT
- Series:
- DEEP
- Family:
- DEEP
- Dimension:
- Ø145x65mm
- Input Voltage:
- 220-240VAC With Driver
- Light Source:
- COB LED
- Material:
- Aluminum+PC
- Life Time:
- 50,000Hrs
- Cut-Out:
- Ø120-Ø130mm
Catalogue Specification
- Light Source:
- COB LED
- Power:
- 25W
- Input Voltage:
- 220-240VAC With Driver
- Driver:
- 580ma/27-40VDC
- Lumen Output:
- 2733lm
- CRI:
- 80+
- Colour Temperature:
- 2700K/3000K/4000K/5000K
- Beam Angle:
- 24°,45°,60°
- IP Rating:
- IP54
- LED Life Time:
- 50,000Hrs
- Dimensions:
- Ø145x65mm
- Cut-Out:
- Ø120-Ø130mm
- Body Finish:
- White RAL 9016
- Material:
- Aluminum+PC
- Heatsink:
- Pure Aluminum
- Warranty:
- Written eligibility and policy confirmation required
Applications
Jewellery Display
Office
Restaurant Dining
Configure your product
LBT3009
Order code
Listed configurationLBT3009.W.827.WWH.60.DR
2 listed configurations · availability requires confirmation
