L02057 Ceiling Light
BASE: L02057DEFAY lighting solution with professional specifications
Specifications at a Glance
15W
Power
1300lm
Lumen Output
3000K
Available Colour Temperatures
CRI 90
Colour Rendering Index
IP65
Protection Rating
60°
Beam Angle
220-240VAC
Input
Ø120mm
Cutout Size
Ø90×H99mm
Body Dimensions
Matt Black
Available Finishes
DALINon-DimmableTriac
Dimming Options
surface-mounted
Mounting Type
OSRAM SMD LED
LED Chip
Die-Cast Aluminum
Material
Technical evidence & warranty
Supporting model-specific declarations/test reports require verification
Evidence requirementsWarranty statusAVAILABLE CONFIGURATIONS
2 listed configurations · availability requires confirmation
Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.
L02057.830.04.60.DDIM
CCT:
3000K
Power:15W
Lumen:1300lm
Beam:
60°
Finish:
CRI 90IP65Black
L02057.830.04.60
CCT:
3000K
Power:15W
Lumen:1300lm
Beam:
CRI 90IP6560°
Need Custom Options?
Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.
Questions about configurations? Contact our sales team for technical assistance.
Product Information
- Category:
- CEILING SURFACE LIGHT
- Series:
- DEFAY
- Family:
- DEFAY
- Dimension:
- Ø90×H99mm
- Input Voltage:
- 220-240VAC
- Light Source:
- OSRAM SMD LED
- Material:
- Die-Cast Aluminum
- Cut-Out:
- Ø120mm
Catalogue Specification
- Light Source:
- OSRAM SMD LED
- Power:
- 15W
- Input Voltage:
- 220-240VAC
- Colour Temperature:
- 3000K/4000K/6000K
- Lumen Output:
- 1300lm
- Beam Angle:
- 60°
- CRI:
- 90
- IP Rating:
- IP65
- Body Finish:
- Black/White
- Dimensions:
- Ø90×H99mm
- Material:
- Die-Cast Aluminum
Applications
Jewellery Display
Office
