LBE2042 Spot Light
BASE: LBE2042DERIN lighting solution with professional specifications
Specifications at a Glance
15W
Power
2700-6500K(Tunable)3000K4000K5000K
Available Colour Temperatures
CRI 90CRI ≥90
Colour Rendering Index
IP32
Protection Rating
38°
Beam Angle
UGR<19
UGR / Optics
350mA/37VDC
Input
Ø78mm
Cutout Size
82mm x 90mm x 70mm
Body Dimensions
White With Sand
Available Finishes
Non-DimmableDALITriac0/1-10V
Dimming Options
ceiling-recessed, track-mounted
Mounting Type
4000K CRI90
LED Chip
aluminium
Material
Technical evidence & warranty
Supporting model-specific declarations/test reports require verification
Evidence requirementsWarranty statusAVAILABLE CONFIGURATIONS
5 listed configurations · availability requires confirmation
Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.
LBE2042.N.940.PAW.38
CCT:
4000K
Power:15W
Beam:
38°
Finish:
CRI ≥90IP32White
LBE2042.W.930.PAW.38
CCT:
3000K
Power:15W
Beam:
38°
Finish:
CRI ≥90IP32White
LBE2042.C.950.PAW.38
CCT:
5000K
Power:15W
Beam:
38°
Finish:
CRI ≥90IP32White
LBE2042.T.9TW5.PAW.38
CCT:
2700-6500K(Tunable)
Power:15W
Beam:
38°
Finish:
CRI 90IP32White
LBE2042.T.9TW.PAW.38.0DR
CCT:
2700-6500K(Tunable)
Power:15W
Beam:
38°
Finish:
CRI 90IP32White
Need Custom Options?
Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.
Questions about configurations? Contact our sales team for technical assistance.
Product Information
- Category:
- SPOT LIGHT
- Series:
- DERIN
- Family:
- DERIN
- Dimension:
- Φ83xH90mm
- Input Voltage:
- 350mA/37VDC
- Light Source:
- 4000K CRI90
- Material:
- aluminium
- Cut-Out:
- Ø78mm
Catalogue Specification
- Driver:
- DC350mA 37V (Without driver)
- Beam Angle:
- 38°
- Cut-Out:
- Ø78mm
- Light Source:
- 4000K CRI90
- Material:
- aluminium
- Body Finish:
- Sand White
- IP Rating:
- IP32
- Dimensions:
- Φ83xH90mm
Applications
Jewellery Display
Retail
Configure your product
LBE2042
Order code
Listed configurationLBE2042.N.940.PAW.38
5 listed configurations · availability requires confirmation
