LBE3015 Down Light

BASE: LBE3015

LAZA lighting solution with professional specifications

LAZA LBE3015 - DOWN LIGHT
Specifications at a Glance
12W
Power
1080lm
Lumen Output
3000K4000K6500K
Available Colour Temperatures
CRI 80
Colour Rendering Index
IP20
Protection Rating
120°
Beam Angle
220-240VAC
Input
Ø110mm
Cutout Size
Ø120×50mm
Body Dimensions
White
Available Finishes
DALINon-DimmableTriac
Dimming Options
ceiling-recessed
Mounting Type
BRIDGELUX
LED Chip
50,000Hrs
LED Life Time
Die-casting aluminum
Material
Technical evidence & warranty

Supporting model-specific declarations/test reports require verification

Evidence requirementsWarranty status

AVAILABLE CONFIGURATIONS

6 listed configurations · availability requires confirmation

Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.

LBE3015.W.930.WWH.120.DR
CCT:
3000K
Power:12W
Lumen:1080lm
Beam:
120°
Finish:
White
CRI 80IP20
LBE3015.N.940.WWH.120.DR
CCT:
4000K
Power:12W
Lumen:1080lm
Beam:
120°
Finish:
White
CRI 80IP20
LBE3015.C.965.WWH.120.DR
CCT:
6500K
Power:12W
Lumen:1080lm
Beam:
120°
Finish:
White
CRI 80IP20
LBE3015.N.840.WWH.120.DR
CCT:
4000K
Power:12W
Lumen:1080lm
Beam:
120°
Finish:
White
CRI 80IP20
LBE3015.C.865.WWH.120.DR
CCT:
6500K
Power:12W
Lumen:1080lm
Beam:
120°
Finish:
White
CRI 80IP20
LBE3015.W.830.WWH.120.DR
CCT:
3000K
Power:12W
Lumen:1080lm
Beam:
120°
Finish:
White
CRI 80IP20

Need Custom Options?

Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.

Questions about configurations? Contact our sales team for technical assistance.
Compatible Accessories
1 items

Recommended accessories for optimal installation and performance

Accessories

Additional components

1

Product Information

Category:
DOWN LIGHT
Series:
LAZA
Family:
LAZA
Dimension:
Ø120×50mm
Input Voltage:
220-240VAC
Light Source:
BRIDGELUX
Material:
Die-casting aluminum
Life Time:
50,000Hrs
Cut-Out:
Ø110mm

Catalogue Specification

Light Source:
BRIDGELUX
Product Type:
DOWNLIGHT
Power:
12W
Input Voltage:
220-240VAC
Lumen Output:
1080lm
Colour Temperature:
2700K/3000K/4000K/5000K/6000K/6500K
CRI:
80
IP Rating:
IP20
Beam Angle:
120°
Material:
Die-casting aluminum
Body Finish:
White
Dimensions:
Ø120×50mm
Cut-Out:
Ø110mm
LED Life Time:
50,000Hrs
Warranty:
Written eligibility and policy confirmation required

Applications

Jewellery Display
Office
