LUMIBRIGHT
LAZIO
LUMI INDOOR
ceiling-recessed
IP20

L01007 Ceiling Light

BASE: L01007

LAZIO lighting solution with professional specifications

LAZIO L01007 - CEILING RECESSED LIGHT
Specifications at a Glance
8W
Power
215-296lm
Lumen Output
2700K3000K4000K6500K
Available Colour Temperatures
CRI 90
Colour Rendering Index
IP20
Protection Rating
15° / 24° / 36° / 60°
Beam Angle
LENS
UGR / Optics
AC220-240V
Input
Ø45mm
Cutout Size
Ø52*H74mm
Body Dimensions
DALINon-DimmableTriac
Dimming Options
ceiling-recessed
Mounting Type
BRIDGELUX
LED Chip
ALUMINUM
Material
Technical evidence & warranty

Supporting model-specific declarations/test reports require verification

Evidence requirementsWarranty status

AVAILABLE CONFIGURATIONS

32 listed configurations · availability requires confirmation

Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.

L01007.965.03.60.DR
CCT:
6500K
Power:8W
Lumen:215-296lm
Beam:
60°
CRI 90IP20
L01007.965.03.36.DR
CCT:
6500K
Power:8W
Lumen:215-296lm
Beam:
36°
CRI 90IP20
L01007.965.03.24.DR
CCT:
6500K
Power:8W
Lumen:215-296lm
Beam:
24°
CRI 90IP20
L01007.965.03.15.DR
CCT:
6500K
Power:8W
Lumen:215-296lm
Beam:
15°
CRI 90IP20
L01007.940.03.60.DR
CCT:
4000K
Power:8W
Lumen:215-296lm
Beam:
60°
CRI 90IP20
L01007.940.03.36.DR
CCT:
4000K
Power:8W
Lumen:215-296lm
Beam:
36°
CRI 90IP20

Need Custom Options?

Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.

Questions about configurations? Contact our sales team for technical assistance.
Compatible Accessories
1 items

Recommended accessories for optimal installation and performance

Accessories

Additional components

1

Product Information

Category:
CEILING RECESSED LIGHT
Series:
LAZIO
Family:
LAZIO
Dimension:
Ø52*H74mm
Input Voltage:
AC220-240V
Light Source:
BRIDGELUX
Material:
ALUMINUM
Cut-Out:
Ø45mm

Catalogue Specification

Light Source:
BRIDGELUX
Power:
8W
Input Voltage:
AC220-240V
Colour Temperature:
2700K/3000K/4000K/6000K/6500K
Lumen Output:
215-296lm
Beam Angle:
15°/24°/36°/60°
CRI:
90
IP Rating:
IP20
Body Finish:
WHITE/BLACK
Dimensions:
Ø52*H74mm
Cut-Out:
Ø45mm
Optics:
LENS
Cover / Lens:
PC
Material:
ALUMINUM

Applications

Jewellery Display
Office
