L01213 Ceiling Light
BASE: L01213LUCCA lighting solution with professional specifications
Specifications at a Glance
26W
Power
2600LM
Lumen Output
2700K3000K4000K
Available Colour Temperatures
CRI ≥92
Colour Rendering Index
IP65
Protection Rating
15° / 24° / 38° / 55°
Beam Angle
REFLECTOR
UGR / Optics
700mA/36VDC
Input
Ø125mm
Cutout Size
Ø136*83
Body Dimensions
BlackWhite
Available Finishes
DALINon-DimmableTriac
Dimming Options
ceiling-recessed
Mounting Type
COB
LED Chip
ALUMINUM
Material
Technical evidence & warranty
Supporting model-specific declarations/test reports require verification
Evidence requirementsWarranty statusAVAILABLE CONFIGURATIONS
48 listed configurations · availability requires confirmation
Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.
L01213.940.03.55
CCT:
4000K
Power:26W
Lumen:2600LM
Beam:
55°
Finish:
CRI ≥92IP65Black
L01213.940.03.38
CCT:
4000K
Power:26W
Lumen:2600LM
Beam:
38°
Finish:
CRI ≥92IP65Black
L01213.940.03.24
CCT:
4000K
Power:26W
Lumen:2600LM
Beam:
24°
Finish:
CRI ≥92IP65Black
L01213.940.03.15
CCT:
4000K
Power:26W
Lumen:2600LM
Beam:
15°
Finish:
CRI ≥92IP65Black
L01213.940.01.55
CCT:
4000K
Power:26W
Lumen:2600LM
Beam:
55°
Finish:
CRI ≥92IP65White
L01213.940.01.38
CCT:
4000K
Power:26W
Lumen:2600LM
Beam:
38°
Finish:
CRI ≥92IP65White
Need Custom Options?
Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.
Questions about configurations? Contact our sales team for technical assistance.
Product Information
- Category:
- CEILING RECESSED LIGHT
- Series:
- LUCCA
- Family:
- LUCCA
- Dimension:
- Ø136*83
- Input Voltage:
- 700mA/36VDC
- Light Source:
- COB
- Material:
- ALUMINUM
- Cut-Out:
- Ø125mm
Catalogue Specification
- Light Source:
- COB
- Power:
- 26W
- Input Voltage:
- 700mA/36VDC
- Colour Temperature:
- 2700K/3000K/4000K/6000K/6500K
- Lumen Output:
- 2600LM
- Beam Angle:
- 15°/24°/38°/55°
- CRI:
- ≥92
- IP Rating:
- IP65
- Body Finish:
- WHITE/BLACK
- Dimensions:
- Ø136*83
- Cut-Out:
- Ø125mm
- Optics:
- REFLECTOR
- Cover / Lens:
- CLEAR GLASS
- Material:
- ALUMINUM
Applications
Jewellery Display
Office
