LUMIBRIGHT
LYRA
LUMI INDOOR
ceiling-recessed
IP20

LBE2043 Spot Light

BASE: LBE2043

LYRA lighting solution with professional specifications

LYRA LBE2043 - SPOT LIGHT
Specifications at a Glance
8W
Power
3000K4000K5000K
Available Colour Temperatures
CRI 90
Colour Rendering Index
IP20
Protection Rating
36°
Beam Angle
200mA
Input
57x57mm
Cutout Size
65x65x63mm
Body Dimensions
Black With SandWhite With Sand
Available Finishes
DALINon-DimmableTriac
Dimming Options
ceiling-recessed, track-mounted
Mounting Type
Bridgelux-COB
LED Chip
Aluminum
Material
Technical evidence & warranty

Supporting model-specific declarations/test reports require verification

Evidence requirementsWarranty status

AVAILABLE CONFIGURATIONS

6 listed configurations · availability requires confirmation

Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.

LBE2043.N.940.PAW.36
CCT:
4000K
Power:8W
Beam:
36°
Finish:
White
CRI 90IP20
LBE2043.W.930.PAW.36
CCT:
3000K
Power:8W
Beam:
36°
Finish:
White
CRI 90IP20
LBE2043.W.930.PAB.36
CCT:
3000K
Power:8W
Beam:
36°
Finish:
Black
CRI 90IP20
LBE2043.N.940.PAB.36
CCT:
4000K
Power:8W
Beam:
36°
Finish:
Black
CRI 90IP20
LBE2043.C.950.PAB.36
CCT:
5000K
Power:8W
Beam:
36°
Finish:
Black
CRI 90IP20
LBE2043.C.950.PAW.36
CCT:
5000K
Power:8W
Beam:
36°
Finish:
White
CRI 90IP20

Need Custom Options?

Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.

Questions about configurations? Contact our sales team for technical assistance.
Compatible Accessories
1 items

Recommended accessories for optimal installation and performance

Accessories

Additional components

1

Product Information

Category:
SPOT LIGHT
Series:
LYRA
Family:
LYRA
Dimension:
65x65x63mm
Input Voltage:
200mA
Light Source:
Bridgelux-COB
Material:
Aluminum
Cut-Out:
57x57mm

Catalogue Specification

Light Source:
Bridgelux-COB
Power:
8W
Driver:
DC 200mA 37V (without driver )
Beam Angle:
36°
Colour Temperature:
4000K
Cut-Out:
57x57mm
Material:
Aluminum
Body Finish:
Sand White, Sand Black
IP Rating:
IP20
Dimensions:
65x65x63mm

Applications

Jewellery Display
Retail
