LUMIBRIGHT
PALERMO
LUMI INDOOR
ceiling-recessed
IP20

L01103 Ceiling Light

BASE: L01103

PALERMO lighting solution with professional specifications

PALERMO L01103 - CEILING RECESSED LIGHT
Specifications at a Glance
18W
Power
1950-2300lm
Lumen Output
3000K4000K5000K5700K
Available Colour Temperatures
CRI 80
Colour Rendering Index
IP20
Protection Rating
90°
Beam Angle
DIFFUSER
UGR / Optics
200-240VAC
Input
Ø140-150mm
Cutout Size
Ø170*45mm
Body Dimensions
BlackWhite
Available Finishes
DALINon-DimmableTriac
Dimming Options
ceiling-recessed
Mounting Type
SMD
LED Chip
ALUMINUM DIE-CAST
Material
Technical evidence & warranty

Supporting model-specific declarations/test reports require verification

Evidence requirementsWarranty status

AVAILABLE CONFIGURATIONS

8 listed configurations · availability requires confirmation

Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.

L01103.857.03.90.DR
CCT:
5700K
Power:18W
Lumen:1950-2300lm
Beam:
90°
Finish:
Black
CRI 80IP20
L01103.857.01.90.DR
CCT:
5700K
Power:18W
Lumen:1950-2300lm
Beam:
90°
Finish:
White
CRI 80IP20
L01103.850.03.90.DR
CCT:
5000K
Power:18W
Lumen:1950-2300lm
Beam:
90°
Finish:
Black
CRI 80IP20
L01103.850.01.90.DR
CCT:
5000K
Power:18W
Lumen:1950-2300lm
Beam:
90°
Finish:
White
CRI 80IP20
L01103.840.03.90.DR
CCT:
4000K
Power:18W
Lumen:1950-2300lm
Beam:
90°
Finish:
Black
CRI 80IP20
L01103.840.01.90.DR
CCT:
4000K
Power:18W
Lumen:1950-2300lm
Beam:
90°
Finish:
White
CRI 80IP20

Need Custom Options?

Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.

Questions about configurations? Contact our sales team for technical assistance.
Compatible Accessories
1 items

Recommended accessories for optimal installation and performance

Accessories

Additional components

1

Product Information

Category:
CEILING RECESSED LIGHT
Series:
PALERMO
Family:
PALERMO
Dimension:
Ø170*45mm
Input Voltage:
200-240VAC
Light Source:
SMD
Material:
ALUMINUM DIE-CAST
Cut-Out:
Ø140-150mm

Catalogue Specification

Light Source:
SMD
Power:
18W
Input Voltage:
200-240VAC
Colour Temperature:
2700K/3000K/4000K/6000K/6500K
Lumen Output:
1950-2300lm
Beam Angle:
90°
CRI:
80
IP Rating:
IP20
Body Finish:
WHITE/BLACK
Dimensions:
Ø170*45mm
Cut-Out:
Ø140-150mm
Optics:
DIFFUSER
Cover / Lens:
PC
Material:
ALUMINUM DIE-CAST

Applications

Jewellery Display
Office
