LBE1005 Track Light

BASE: LBE1005

TRACK lighting solution with professional specifications

TRACK LBE1005 - SPOT LIGHT
Specifications at a Glance
20W
Power
2200lm
Lumen Output
2700K3000K
Available Colour Temperatures
CRI 80+/90+
Colour Rendering Index
IP20
Protection Rating
15° / 24° / 36°
Beam Angle
220-240VAC
Input
90x90mm
Cutout Size
Ø78*H100mm
Body Dimensions
Black With SandWhite With Sand
Available Finishes
DALINon-DimmableTriac
Dimming Options
track-mounted
Mounting Type
TYF COB
LED Chip
50,000Hrs
LED Life Time
Aluminum
Material
Technical evidence & warranty

Supporting model-specific declarations/test reports require verification

Evidence requirementsWarranty status

AVAILABLE CONFIGURATIONS

12 listed configurations · availability requires confirmation

Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.

LBE1005.W.930.PAW.36
CCT:
3000K
Power:20W
Lumen:2200lm
Beam:
36°
Finish:
White
CRI 80+/90+IP20
LBE1005.W.927.PAW.36
CCT:
2700K
Power:20W
Lumen:2200lm
Beam:
36°
Finish:
White
CRI 80+/90+IP20
LBE1005.W.930.PAB.36
CCT:
3000K
Power:20W
Lumen:2200lm
Beam:
36°
Finish:
Black
CRI 80+/90+IP20
LBE1005.W.927.PAB.36
CCT:
2700K
Power:20W
Lumen:2200lm
Beam:
36°
Finish:
Black
CRI 80+/90+IP20
LBE1005.W.930.PAW.24
CCT:
3000K
Power:20W
Lumen:2200lm
Beam:
24°
Finish:
White
CRI 80+/90+IP20
LBE1005.W.927.PAW.24
CCT:
2700K
Power:20W
Lumen:2200lm
Beam:
24°
Finish:
White
CRI 80+/90+IP20

Need Custom Options?

Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.

Questions about configurations? Contact our sales team for technical assistance.
Compatible Accessories
1 items

Recommended accessories for optimal installation and performance

Accessories

Additional components

1

Product Information

Category:
TRACK LIGHT
Family:
SENSE
Dimension:
Ø78*H100mm
Input Voltage:
220-240VAC
Light Source:
TYF COB
Material:
Aluminum
Life Time:
50,000Hrs
Cut-Out:
90x90mm

Catalogue Specification

Light Source:
TYF COB
Power:
20W
Input Voltage:
220-240VAC
Lumen Output:
2200lm
CRI:
80+/90+
Colour Temperature:
2700K/3000K/3500K/4000K
Beam Angle:
15/24/36°
Power Factor:
0.90
IP Rating:
IP20
LED Life Time:
50,000Hrs
Dimensions:
Ø78*H100mm
Body Finish:
Black / White / Silver
Material:
Aluminum
Reflector:
Aluminum
Heatsink:
Die cast aluminum
Warranty:
Written eligibility and policy confirmation required
Catalogue conformity claim (evidence not verified):
CE
Driver:
KGP integrated driver

Applications

Jewellery Display
Retail
