L01221 Ceiling Light
BASE: L01221SIENA lighting solution with professional specifications
Specifications at a Glance
20W
Power
1830LM
Lumen Output
2700K3000K4000K
Available Colour Temperatures
CRI ≥92
Colour Rendering Index
IP20
Protection Rating
100°
Beam Angle
DIFFUSER
UGR / Optics
700mA/36VDC
Input
Ø160-165mm
Cutout Size
Ø182*57
Body Dimensions
BlackWhite
Available Finishes
DALINon-DimmableTriac
Dimming Options
ceiling-recessed
Mounting Type
COB
LED Chip
ALUMINUM DIE-CAST
Material
Technical evidence & warranty
Supporting model-specific declarations/test reports require verification
Evidence requirementsWarranty statusAVAILABLE CONFIGURATIONS
12 listed configurations · availability requires confirmation
Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.
L01221.940.03.100
CCT:
4000K
Power:20W
Lumen:1830LM
Beam:
100°
Finish:
CRI ≥92IP20Black
L01221.940.01.100
CCT:
4000K
Power:20W
Lumen:1830LM
Beam:
100°
Finish:
CRI ≥92IP20White
L01221.930.03.100
CCT:
3000K
Power:20W
Lumen:1830LM
Beam:
100°
Finish:
CRI ≥92IP20Black
L01221.930.01.100
CCT:
3000K
Power:20W
Lumen:1830LM
Beam:
100°
Finish:
CRI ≥92IP20White
L01221.927.03.100
CCT:
2700K
Power:20W
Lumen:1830LM
Beam:
100°
Finish:
CRI ≥92IP20Black
L01221.927.01.100
CCT:
2700K
Power:20W
Lumen:1830LM
Beam:
100°
Finish:
CRI ≥92IP20White
Need Custom Options?
Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.
Questions about configurations? Contact our sales team for technical assistance.
Product Information
- Category:
- CEILING RECESSED LIGHT
- Series:
- SIENA
- Family:
- SIENA
- Dimension:
- Ø182*57
- Input Voltage:
- 700mA/36VDC
- Light Source:
- COB
- Material:
- ALUMINUM DIE-CAST
- Cut-Out:
- Ø160-165mm
Catalogue Specification
- Light Source:
- COB
- Power:
- 20W
- Input Voltage:
- 700mA/36VDC
- Colour Temperature:
- 2700K/3000K/4000K/6000K/6500K
- Lumen Output:
- 1830LM
- Beam Angle:
- 100°
- CRI:
- ≥92
- IP Rating:
- IP20
- Body Finish:
- WHITE/BLACK
- Dimensions:
- Ø182*57
- Cut-Out:
- Ø160-165mm
- Optics:
- DIFFUSER
- Cover / Lens:
- PC
- Material:
- ALUMINUM DIE-CAST
Applications
Jewellery Display
Office
Configure your product
L01221
Order code
Listed configurationL01221.940.03.100
12 listed configurations · availability requires confirmation
