L01228 Ceiling Light
BASE: L01228SORIA lighting solution with professional specifications
Specifications at a Glance
12W
Power
780Lm
Lumen Output
3000K4000K5000K6000K
Available Colour Temperatures
CRI 90
Colour Rendering Index
IP20
Protection Rating
12° / 24° / 36°
Beam Angle
LENS
UGR / Optics
AC220-240V
Input
Ø75mm
Cutout Size
Φ85*76
Body Dimensions
White
Available Finishes
DALINon-DimmableTriac
Dimming Options
ceiling-recessed
Mounting Type
CREE
LED Chip
ALUMINUM
Material
Technical evidence & warranty
Supporting model-specific declarations/test reports require verification
Evidence requirementsWarranty statusAVAILABLE CONFIGURATIONS
12 listed configurations · availability requires confirmation
Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.
L01228.960.01.36.DR
CCT:
6000K
Power:12W
Lumen:780Lm
Beam:
36°
Finish:
CRI 90IP20White
L01228.950.01.36.DR
CCT:
5000K
Power:12W
Lumen:780Lm
Beam:
36°
Finish:
CRI 90IP20White
L01228.940.01.36.DR
CCT:
4000K
Power:12W
Lumen:780Lm
Beam:
36°
Finish:
CRI 90IP20White
L01228.930.01.36.DR
CCT:
3000K
Power:12W
Lumen:780Lm
Beam:
36°
Finish:
CRI 90IP20White
L01228.960.01.24.DR
CCT:
6000K
Power:12W
Lumen:780Lm
Beam:
24°
Finish:
CRI 90IP20White
L01228.950.01.24.DR
CCT:
5000K
Power:12W
Lumen:780Lm
Beam:
24°
Finish:
CRI 90IP20White
Need Custom Options?
Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.
Questions about configurations? Contact our sales team for technical assistance.
Product Information
- Category:
- CEILING RECESSED LIGHT
- Series:
- SORIA
- Family:
- SORIA
- Dimension:
- Φ85*76
- Input Voltage:
- AC220-240V
- Light Source:
- CREE
- Material:
- ALUMINUM
- Cut-Out:
- Ø75mm
Catalogue Specification
- Light Source:
- CREE
- Power:
- 12W
- Input Voltage:
- AC220-240V
- Colour Temperature:
- 2700K/3000K/4000K/6000K/6500K
- Lumen Output:
- 780Lm
- Beam Angle:
- 12°/24°/36°
- CRI:
- 90
- IP Rating:
- IP20
- Body Finish:
- SAND WHITE
- Dimensions:
- Φ85*76
- Cut-Out:
- Ø75mm
- Optics:
- LENS
- Cover / Lens:
- PC
- Material:
- ALUMINUM
Applications
Jewellery Display
Office
Configure your product
L01228
Order code
Listed configurationL01228.960.01.36.DR
12 listed configurations · availability requires confirmation
