LBE2076 Spot Light
BASE: LBE2076TENUS lighting solution with professional specifications
Specifications at a Glance
10W
Power
2700K3000K4000K6000K
Available Colour Temperatures
CRI 90
Colour Rendering Index
IP20
Protection Rating
18° / 24° / 36°
Beam Angle
220-240VAC
Input
Ø70mm
Cutout Size
Ø76*H86mm
Body Dimensions
Black With Sand+Matt BlackWhite With Sand+Matt Black
Available Finishes
DALINon-DimmableTriac
Dimming Options
ceiling-recessed, track-mounted
Mounting Type
BRIDGELUX LED
LED Chip
Technical evidence & warranty
Supporting model-specific declarations/test reports require verification
Evidence requirementsWarranty statusAVAILABLE CONFIGURATIONS
24 listed configurations · availability requires confirmation
Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.
LBE2076.W.927.PAB+PBK.24.DR
CCT:
2700K
Power:10W
Beam:
24°
Finish:
CRI 90IP20Black With Sand+Matt Black
LBE2076.W.930.PAB+PBK.24.DR
CCT:
3000K
Power:10W
Beam:
24°
Finish:
CRI 90IP20Black With Sand+Matt Black
LBE2076.W.930.PAW+PBK.36.DR
CCT:
3000K
Power:10W
Beam:
36°
Finish:
CRI 90IP20White With Sand+Matt Black
LBE2076.W.927.PAB+PBK.18.DR
CCT:
2700K
Power:10W
Beam:
18°
Finish:
CRI 90IP20Black With Sand+Matt Black
LBE2076.W.927.PAW+PBK.18.DR
CCT:
2700K
Power:10W
Beam:
18°
Finish:
CRI 90IP20White With Sand+Matt Black
LBE2076.W.930.PAB+PBK.18.DR
CCT:
3000K
Power:10W
Beam:
18°
Finish:
CRI 90IP20Black With Sand+Matt Black
Need Custom Options?
Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.
Questions about configurations? Contact our sales team for technical assistance.
Compatible Accessories
Product Information
- Category:
- SPOT LIGHT
- Series:
- Tenus
- Family:
- TENUS
- Dimension:
- Ø76*H86mm
- Input Voltage:
- 220-240VAC
- Light Source:
- BRIDGELUX LED
- Cut-Out:
- Ø70mm
Catalogue Specification
- Power:
- 10W
- Light Source:
- BRIDGELUX LED
- CRI:
- 90
- Colour Temperature:
- 2700K/3000K/4000K/6000K
- Driver:
- EAGERISE DRIVER
- Power Factor:
- 0.5
- Flicker:
- no flicker
- Reflector:
- SHINLAND-CLEAR
- Beam Angle:
- 18D/24D/36D
- Dimensions:
- Ø76*H86mm
- Cut-Out:
- Ø70mm
- Body Finish:
- White,Black
- Front Ring:
- black
Applications
Jewellery Display
Retail
Configure your product
LBE2076
Order code
Listed configurationLBE2076.W.927.PAB+PBK.24.DR
24 listed configurations · availability requires confirmation
