LBE3009 Down Light

LBE3009 is the TIEF LBE3009 - DOWN LIGHT lighting model in the lumi indoor catalogue, listed under DOWN LIGHT. This page keeps the specifications, configuration choices and project notes for LBE3009 together, so it can be compared with other TIEF models without substituting the dimensions or options of a neighbouring article.

The LBE3009 catalogue record lists power: 12W. Coordinate this load with the circuit schedule and the selected control gear.

The LBE3009 catalogue record lists body dimensions: Φ135x126mm. Check the housing against the architectural detail and the space reserved for installation.

The LBE3009 catalogue record lists cut-out: Φ128 mm. Use the opening dimension separately from the outside body size when coordinating the finished surface.

The LBE3009 catalogue record lists colour temperature: 2700K, 3000K, 4000K, 6000K. Compare the listed colour choices with finishes, surrounding light and the intended atmosphere.

The LBE3009 catalogue record lists colour rendering: ≥90. Include this catalogue value in the material and display-lighting comparison for the project.

The LBE3009 catalogue record lists optical distribution: 38°. Compare the listed option with target distance, spacing and the surface being illuminated.

The LBE3009 catalogue record lists enclosure rating: IP20. Coordinate this rating with the actual exposure, cleaning regime and installation conditions.

The LBE3009 catalogue record lists electrical requirement: 220-240VAC. Keep the stated unit alongside the driver and control specification; a current rating must not be treated as a mains voltage.

The LBE3009 catalogue record lists finish or material: Sand White. Review the stated construction alongside adjoining architectural materials and sample approvals.

The LBE3009 catalogue record lists mounting: recessed. Check the fixing arrangement and access for installation before finalising the detail.

Compare LBE3009 with the lighting brief for the room, feature or circulation area being designed. Review the available model data alongside the architectural layout, viewing positions and intended control scenes. Keep the article reference visible in the schedule so the design team can coordinate the selected product with its mounting detail and any associated equipment. Project-specific suitability depends on that complete selection.

LBE3009 has 3 listed order-code configurations. Examples from this model are LBE3009.N.940.PAW.38, LBE3009.W.930.PAW.38, LBE3009.C.950.PAW.38. Use the exact listed combination when selecting finishes, colour temperature or optical options; an option appearing elsewhere in the family is not automatically an orderable combination for this article.

For a LBE3009 project submission, retain this model reference with the drawings and the selected configuration. Include the relevant dimensions, optical information and installation requirements in the coordination review. Where a document or value is not available on the page, request the model-specific information from the specification team rather than copying a value from another TIEF article.
