LUMIBRIGHT
TURIN
LUMI INDOOR
ceiling-recessed
IP20

L01224 Ceiling Light

BASE: L01224

TURIN lighting solution with professional specifications

TURIN L01224 - CEILING RECESSED LIGHT
Specifications at a Glance
12W
Power
744Lm
Lumen Output
3000K4000K5000K6000K
Available Colour Temperatures
CRI 90
Colour Rendering Index
IP20
Protection Rating
15° / 24° / 38° / 60°
Beam Angle
LENS
UGR / Optics
AC220-240V
Input
Ø55mm
Cutout Size
Φ58*70
Body Dimensions
BlackWhite
Available Finishes
DALINon-DimmableTriac
Dimming Options
ceiling-recessed
Mounting Type
CREE
LED Chip
ALUMINUM
Material
Technical evidence & warranty

Supporting model-specific declarations/test reports require verification

Evidence requirementsWarranty status

AVAILABLE CONFIGURATIONS

32 listed configurations · availability requires confirmation

Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.

L01224.960.03.60.DR
CCT:
6000K
Power:12W
Lumen:744Lm
Beam:
60°
Finish:
Black
CRI 90IP20
L01224.960.01.60.DR
CCT:
6000K
Power:12W
Lumen:744Lm
Beam:
60°
Finish:
White
CRI 90IP20
L01224.960.03.38.DR
CCT:
6000K
Power:12W
Lumen:744Lm
Beam:
38°
Finish:
Black
CRI 90IP20
L01224.960.01.38.DR
CCT:
6000K
Power:12W
Lumen:744Lm
Beam:
38°
Finish:
White
CRI 90IP20
L01224.960.03.24.DR
CCT:
6000K
Power:12W
Lumen:744Lm
Beam:
24°
Finish:
Black
CRI 90IP20
L01224.960.01.24.DR
CCT:
6000K
Power:12W
Lumen:744Lm
Beam:
24°
Finish:
White
CRI 90IP20

Need Custom Options?

Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.

Questions about configurations? Contact our sales team for technical assistance.
Compatible Accessories
1 items

Recommended accessories for optimal installation and performance

Accessories

Additional components

1

Product Information

Category:
CEILING RECESSED LIGHT
Series:
TURIN
Family:
TURIN
Dimension:
Φ58*70
Input Voltage:
AC220-240V
Light Source:
CREE
Material:
ALUMINUM
Cut-Out:
Ø55mm

Catalogue Specification

Light Source:
CREE
Power:
12W
Input Voltage:
AC220-240V
Colour Temperature:
2700K/3000K/4000K/6000K/6500K
Lumen Output:
744Lm
Beam Angle:
15°/24°/38°/60°
CRI:
90
IP Rating:
IP20
Body Finish:
WHITE/BLACK
Dimensions:
Φ58*70
Cut-Out:
Ø55mm
Optics:
LENS
Cover / Lens:
PC
Material:
ALUMINUM

Applications

Jewellery Display
Office

Configure your product

L01224

Order code

Listed configuration

L01224.960.03.60.DR

32 listed configurations · availability requires confirmation
