L02016 Spot Light
BASE: L02016VASTE lighting solution with professional specifications
Specifications at a Glance
10W
Power
850-900LM
Lumen Output
2700K3000K4000K5000K
Available Colour Temperatures
CRI 80
Colour Rendering Index
IP20
Protection Rating
15° / 24° / 36°
Beam Angle
REFLECTOR
UGR / Optics
AC100-240V
Input
Ø80mm
Cutout Size
Ø80*130mm
Body Dimensions
BlackWhite
Available Finishes
DALINon-DimmableTriac
Dimming Options
surface-mounted
Mounting Type
COB
LED Chip
ALUMINUM
Material
Technical evidence & warranty
Supporting model-specific declarations/test reports require verification
Evidence requirementsWarranty statusAVAILABLE CONFIGURATIONS
26 listed configurations · availability requires confirmation
Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.
L02016.830.01.02.24
CCT:
3000K
Power:10W
Lumen:850-900LM
Beam:
24°
Finish:
CRI 80IP20White
L02016.840.01.05.15
CCT:
4000K
Power:10W
Lumen:850-900LM
Beam:
15°
Finish:
CRI 80IP20White
L02016.850.03.36
CCT:
5000K
Power:10W
Lumen:850-900LM
Beam:
36°
Finish:
CRI 80IP20Black
L02016.850.03.24
CCT:
5000K
Power:10W
Lumen:850-900LM
Beam:
24°
Finish:
CRI 80IP20Black
L02016.850.03.15
CCT:
5000K
Power:10W
Lumen:850-900LM
Beam:
15°
Finish:
CRI 80IP20Black
L02016.850.01.36
CCT:
5000K
Power:10W
Lumen:850-900LM
Beam:
36°
Finish:
CRI 80IP20White
Need Custom Options?
Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.
Questions about configurations? Contact our sales team for technical assistance.
Product Information
- Category:
- CEILING SURFACE LIGHT
- Series:
- VASTE
- Family:
- VASTE
- Dimension:
- Ø80*130mm
- Input Voltage:
- AC100-240V
- Light Source:
- COB
- Material:
- ALUMINUM
- Cut-Out:
- Ø80mm
Catalogue Specification
- Light Source:
- COB
- Power:
- 10W
- Input Voltage:
- AC100-240V
- Colour Temperature:
- 2700K/3000K/4000K/5000K
- Lumen Output:
- 850-900LM
- Beam Angle:
- 15°/24°/36°
- CRI:
- 80
- IP Rating:
- IP20
- Body Finish:
- WHITE/BLACK
- Dimensions:
- Ø80*130mm
- Optics:
- REFLECTOR
- Cover / Lens:
- CLEAR GLASS
- Material:
- ALUMINUM
Applications
Hospitality
Jewellery Display
Office
Residential
Retail
Configure your product
L02016
Order code
Listed configurationL02016.830.01.02.24
26 listed configurations · availability requires confirmation
