LUMIBRIGHT
WERDER
LUMI INDOOR
ceiling-recessed
IP65

L01257 Spot Light

BASE: L01257

WERDER lighting solution with professional specifications

WERDER L01257 - SPOT LIGHT
Specifications at a Glance
12W
Power
1100LM
Lumen Output
3000K4000K6000K
Available Colour Temperatures
CRI 80
Colour Rendering Index
IP65
Protection Rating
15° / 24° / 38° / 50°
Beam Angle
220-240VAC
Input
138x/33.5mm
Cutout Size
148x43.5/x60mm
Body Dimensions
BlackGreyWhite
Available Finishes
DALINon-DimmableTriac
Dimming Options
ceiling-recessed
Mounting Type
CREE
LED Chip
ALUMINUM
Material
Technical evidence & warranty

Supporting model-specific declarations/test reports require verification

Evidence requirementsWarranty status

AVAILABLE CONFIGURATIONS

36 listed configurations · availability requires confirmation

Smart PDF Generation: Use the configurator above to select your specific options (light type, CCT, finish, length), then click "Download Datasheet" to generate a custom PDF for your exact configuration.

L01257.830.03.24.DR
CCT:
3000K
Power:12W
Lumen:1100LM
Beam:
24°
Finish:
Black
CRI 80IP65
L01257.860.09.50.DR
CCT:
6000K
Power:12W
Lumen:1100LM
Beam:
50°
Finish:
Grey
CRI 80IP65
L01257.840.09.50.DR
CCT:
4000K
Power:12W
Lumen:1100LM
Beam:
50°
Finish:
Grey
CRI 80IP65
L01257.830.09.50.DR
CCT:
3000K
Power:12W
Lumen:1100LM
Beam:
50°
Finish:
Grey
CRI 80IP65
L01257.860.03.50.DR
CCT:
6000K
Power:12W
Lumen:1100LM
Beam:
50°
Finish:
Black
CRI 80IP65
L01257.840.03.50.DR
CCT:
4000K
Power:12W
Lumen:1100LM
Beam:
50°
Finish:
Black
CRI 80IP65

Need Custom Options?

Looking for different CCT, finish, beam angle, or other specifications? Our team can help configure the perfect solution for your project.

Questions about configurations? Contact our sales team for technical assistance.
Compatible Accessories
1 items

Recommended accessories for optimal installation and performance

Accessories

Additional components

1

Product Information

Category:
SPOT LIGHT
Series:
WERDER
Family:
WERDER
Dimension:
148x43.5/x60mm
Input Voltage:
220-240VAC
Light Source:
CREE
Material:
ALUMINUM
Cut-Out:
138x/33.5mm

Catalogue Specification

Light Source:
CREE
Power:
12W
Input Voltage:
220-240VAC
Colour Temperature:
2700K/3000K/4000K/6000K/6500K
Beam Angle:
15°/24°/38°/50°
CRI:
80
IP Rating:
IP65
Body Finish:
WHITE/BLACK/GREY
Dimensions:
148x43.5/x60mm
Cut-Out:
138x/33.5mm
Material:
ALUMINUM

Applications

Jewellery Display
Retail

Configure your product

L01257

Order code

Listed configuration

L01257.830.03.24.DR

36 listed configurations · availability requires confirmation
