Spot Light
HALCON
6 variants·luminaire·ceiling recessed
Product View
Configuration
Select Specification
Power
Beam Angle
CCT
Finish
IP Rating
Select attributes to narrow down variants
All Variants (6)
Dimensions
Technical Drawing
Drawing and sizes shown for model LB2966.
Size — model LB2966
Φ93.5×H95mm
Technical Data
Full Specification
| Dimensions | Φ93.5×H95mm |
|---|---|
| Cut-out | On request |
| Power | 7W |
| Lumen output | 600lm |
| Efficacy | 86 lm/W |
| Optics / beam angle | 24° · 36° |
| Colour temperature | 3000K · 4000K · 5000K |
| CRI / R9 | 90 · >90 |
| UGR | On request |
| IP rating | IP20 |
| IK rating | On request |
| Ambient temperature (Ta) | On request |
| Driver | On request |
| Dimming / control | On request |
| Input voltage | 220-240VAC |
| Light source | On request |
| Material | On request |
| Finish | black+golden · White · black+copper |
| Mounting / installation | On request |
| Net weight | On request |
| Certification | On request |
| Lifetime | On request |
| Warranty | On request |
| Lead time | On request |
10 of 24 specification rows published from the 2026 master data. Ask our technical team for anything shown as “on request”.
Specifications
At a Glance
7W
Power
36°
Beam Angle
3000K
Colour Temperature
CRI 90
Colour Rendering
IP20
Protection Rating
3 finishes
Body Finish
Φ93.5×H95mm
Dimensions
