Spot Light
LILY T
24 variants·luminaire·ceiling recessed
Product View
Configuration
Select Specification
Power
Beam Angle
CCT
Finish
IP Rating
Select attributes to narrow down variants
All Variants (24)
| Code | Power | CCT | Beam | CRI | Finish | Size | |
|---|---|---|---|---|---|---|---|
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | White | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | white | Ø58x75mm | |
| LB2847 | 3W | 2700K, 3000K, 4000K, 5000K, 6000K | 15° | 80 | White | Ø58x75mm |
Dimensions
Technical Drawing
Drawing and sizes shown for model LB2847.
Size — model LB2847
Ø58x75mm
Cut-Out
Ø50mm
Technical Data
Full Specification
| Dimensions | Ø58x75mm |
|---|---|
| Cut-out | Ø50mm |
| Power | 3W · 3W/5W |
| Lumen output | 240lm/400lm |
| Efficacy | 133 lm/W |
| Optics / beam angle | 15° · 24° · 25° · 45° +1 more |
| Colour temperature | 2700K · 3000K · 4000K · 5000K +1 more |
| CRI / R9 | 80 · >80 |
| UGR | On request |
| IP rating | IP65 |
| IK rating | On request |
| Ambient temperature (Ta) | On request |
| Driver | On request |
| Dimming / control | On request |
| Input voltage | 36VDC |
| Light source | On request |
| Material | Aluminum |
| Finish | white |
| Mounting / installation | On request |
| Net weight | On request |
| Certification | On request |
| Lifetime | On request |
| Warranty | On request |
| Lead time | On request |
12 of 24 specification rows published from the 2026 master data. Ask our technical team for anything shown as “on request”.
Specifications
At a Glance
3W
Power
15°
Beam Angle
5 CCT
2700K, 3000K, 4000K, 5000K, 6000K
CRI 80
Colour Rendering
IP65
Protection Rating
2 finishes
Body Finish
Ø58x75mm
Dimensions
Ø50mm
Cut-Out
